SICK WSO26I Series Light Curtain Sender, 1 Beam(s)

View all Light Curtains

Subtotal (1 unit)*

£145.68

(exc. VAT)

£174.82

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£145.68

*price indicative

RS Stock No.:
285-2447
Mfr. Part No.:
WSO26I-243ZZ1A0ZZZZLLZZZZZZZZ1
Brand:
SICK
Find similar products by selecting one or more attributes.
Select all

Brand

SICK

Series

WSO26I

Component Type

Sender

Safety Type

2

SIL IEC 61508

SIL 1

PL EN ISO 13849-1

c

Number of Beams

1

Maximum Scanning Distance

50m

Maximum Response Time

0.5 ms

Supply Voltage

24 V dc

Height

48.1mm

Length

82.2mm

Width

26.4mm

Terminal Type

M12 Connector

Dimensions

26.4 x 48.1 x 82.2 mm

COO (Country of Origin):
DE

Overview


The L25 and L26 product families from SICK represent a new generation of single-beam photoelectric safety switch for type 2 applications, which, in combination with an external test device, facilitate operations and make processes safer and more efficient. Thanks to the innovative BluePilot operating concept with feedback LED, the alignment of sender and receiver is easier than ever.

Smart Sensor diagnostic functions provide insight into the status of each individual sensor at all times, thus creating the basis for efficient communication. Thanks to the ultra rugged VISTAL® housing and predictive maintenance, the L25 and L26 are extremely reliable and prevent unscheduled machine downtime.

At a glance


BluePilot: optical alignment aid
Smart Sensor: efficient communication with IO-Link
Ultra rugged VISTAL® housing
Enclosure rating: IP66, IP67 and IP69K
Typical scanning range of up to 50 m
Type of light: IR light and visible red light
Standardized connection and mounting systems
Type 2, PL c, SIL1

Your Benefit


Quick and precise alignment of the sender and the receiver thanks to the PinPoint LED in combination with BluePilot
Increased productivity: Smart Sensor diagnostic functions always available via IO-Link
Cost efficiency: IP66, IP67 and IP69K guarantee a long service life. The ultra rugged VISTAL® housing withstands extreme environmental influences with ease
Flexibility: The large scanning range of up to 50 m enables more application possibilities
High availability: IR light and red light variants prevent interference and a superimposition of sensor signals
Easy order processing thanks to the standardized connection and mounting systems

Applications


Fields of applications
Machine tools: access protection and area safeguarding
Consumer goods: access protection for cutting machines
Storage and conveyor (intralogistics): access protection for mobile storage systems (high-bay warehouse)
