TE Connectivity 26mm Diameter for use with Cree XLamp MP-L LEDs
- RS Stock No.:
- 718-8848
- Mfr. Part No.:
- 2106946-1
- Brand:
- TE Connectivity
Discontinued
- RS Stock No.:
- 718-8848
- Mfr. Part No.:
- 2106946-1
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Diameter | 26mm | |
| For Use With | Cree XLamp MP-L LEDs | |
| Number of Legs | 6 | |
| Mounting Type | Screw | |
| Voltage Rating | 30V dc | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Diameter 26mm | ||
For Use With Cree XLamp MP-L LEDs | ||
Number of Legs 6 | ||
Mounting Type Screw | ||
Voltage Rating 30V dc | ||
Solderless LED Socket, Type CM
The Solderless LED Socket, Type CM series, from TE Connectivity, provides a solderless Class 2 parallel (6 conductor) quick termination method for Cree’s XLamp® MP-L™ LED series (e.g. stock no. 725-0123). The LED sockets use solderless termination techniques to allow easy integration of the LED into the end customer’s lighting fixtures using simple screw-down installation.
The solderless LED sockets also feature robust, snap attachment for LEDIL’s Tyra series of reflector optics, e.g. stock no. 724-0766.
The range includes: LED to wire and LED to board versions, with or without optic latches.
The solderless LED sockets also feature robust, snap attachment for LEDIL’s Tyra series of reflector optics, e.g. stock no. 724-0766.
The range includes: LED to wire and LED to board versions, with or without optic latches.
Solderless termination to Cree XLamp MP-L LEDs
Snap-on optics assembly using LEDIL’s Tyra series reflector optics
6 line parallel terminations in both wire and board versions
Housing: 94 V-0 rated high temperature resistant thermoplastic
Contacts: Base material copper alloy, Silver plated interface to Cree XLamp MP-L LED, Tin plated interface to AMP Mini CT or to PCB
Solderless LED sockets are ideal for applications including; commercial and residential lighting fixtures and integrated custom lighting
Snap-on optics assembly using LEDIL’s Tyra series reflector optics
6 line parallel terminations in both wire and board versions
Housing: 94 V-0 rated high temperature resistant thermoplastic
Contacts: Base material copper alloy, Silver plated interface to Cree XLamp MP-L LED, Tin plated interface to AMP Mini CT or to PCB
Solderless LED sockets are ideal for applications including; commercial and residential lighting fixtures and integrated custom lighting
Note
LED Mounting Hardware - TE Connectivity
