eldoLED 1 Output LED Driver, 55V, 30 W, 350mA 1/10 V LED Driver
- RS Stock No.:
- 144-2790
- Mfr. Part No.:
- EC0361A4
- Brand:
- eldoLED
Subtotal (1 unit)*
£55.52
(exc. VAT)
£66.62
(inc. VAT)
FREE delivery for orders over £60.00
Last RS stock
- Final 86 unit(s), ready to ship
Units | Per unit |
|---|---|
| 1 + | £55.52 |
*price indicative
- RS Stock No.:
- 144-2790
- Mfr. Part No.:
- EC0361A4
- Brand:
- eldoLED
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | eldoLED | |
| Product Type | LED Driver | |
| Output Voltage | 55V | |
| Maximum Output Power | 30W | |
| Input Voltage | 120, 250, 277, 120, 250V ac | |
| Mount Type | Surface | |
| Sub Type | LED Driver | |
| Dimming Operation | 1/10 V | |
| Input Voltage Type | AC | |
| Terminal Type | Push-in | |
| Driver Current | 350mA | |
| Operating Modes | Constant Current | |
| Number of Outputs | 1 | |
| Standards/Approvals | ENEC, UL, EL, CE | |
| Series | Ecodrive | |
| Configuration | Enclosed | |
| Power Dissipation | 0.5W | |
| Primary Type | AC-DC | |
| Select all | ||
|---|---|---|
Brand eldoLED | ||
Product Type LED Driver | ||
Output Voltage 55V | ||
Maximum Output Power 30W | ||
Input Voltage 120, 250, 277, 120, 250V ac | ||
Mount Type Surface | ||
Sub Type LED Driver | ||
Dimming Operation 1/10 V | ||
Input Voltage Type AC | ||
Terminal Type Push-in | ||
Driver Current 350mA | ||
Operating Modes Constant Current | ||
Number of Outputs 1 | ||
Standards/Approvals ENEC, UL, EL, CE | ||
Series Ecodrive | ||
Configuration Enclosed | ||
Power Dissipation 0.5W | ||
Primary Type AC-DC | ||
- COO (Country of Origin):
- MX
Natural dimming to 1% (Hybrid HydraDrive)
Symbiosis: add Value with sensing, connecting, protecting, tooling, communicating, sharing and lighting dynamics features
Programmable to fit application
Independent driver
Low inrush and THD
High power factor and efficiency
Compatible with HD studio Camera
EN 61347-1/-2-13, EN 62384, EN 55015, EN 55022, EN 61000-3-2, EN 61547, EN 60929 Annex E
UL: Recognized Component (E333135), according to UL1310 and UL8750. US/Canada: Class 2 output
ENEC by DEKRA
EL
RCM by SAA
ECOdrive, a programmable digital LED driver, provides standard LED fixtures with the smoothest flicker-free dimming to 1%. It has a single configurable constant current LED output, making it simple to design in. Symbiosis ensures the LED driver works seamlessly together with LED modules, controls and intelligent luminaire elements.
