RS PRO, 3/42 V Output, 10 W Output, 100 to 450 mA

RS Stock No.:: 360-648
Brand:: RS PRO

RS PRO, 3/42 V Output, 10 W Output, 100 to 450 mA

Subtotal (1 unit)*

£52.33

(exc. VAT)

£62.80

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

Plus 94 unit(s) shipping from 16 February 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£52.33

*price indicative

RS Stock No.:: 360-648
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Output Voltage	3/42 V
	Product Type	LED Driver
	Maximum Output Power	10W
	Input Voltage	200 → 240 V ac
	Terminal Type	Screw
	Input Voltage Type	AC
	IP Rating	IP20
	LED Voltage	3/42 V
	Operating Modes	Constant Current
	Driver Current	100 to 450 mA
	Standards/Approvals	11, 3, 4, 5, 6, EN55015, EN61000-3-2, EN61000-4-2, EN61347-1, EN61347-2-13, EN61547, FCC Part 15B, UL8750
	Series	RS PRO
	Number of Outputs	8
	Primary Type	AC

	Select all
	Brand RS PRO
	Output Voltage 3/42 V
	Product Type LED Driver
	Maximum Output Power 10W
	Input Voltage 200 → 240 V ac
	Terminal Type Screw
	Input Voltage Type AC
	IP Rating IP20
	LED Voltage 3/42 V
	Operating Modes Constant Current
	Driver Current 100 to 450 mA
	Standards/Approvals 11, 3, 4, 5, 6, EN55015, EN61000-3-2, EN61000-4-2, EN61347-1, EN61347-2-13, EN61547, FCC Part 15B, UL8750
	Series RS PRO
	Number of Outputs 8
	Primary Type AC

COO (Country of Origin):: CN

RS PRO LED Driver, 10W Triac Dimming

This high-performance, dimmable constant current output LED driver is designed to provide efficient, reliable power for LED lighting systems. It offers seamless integration into smart lighting environments with compatibility with leading and trailing edge dimmers.

Features and Benefits

Constant Current Mode Output: Multiple levels selectable by dip switch for flexibility

Dimming Function: Triac/phase cut dimming for smooth light control

Compatibility: Works with leading or trailing edge triac dimmers for versatile use

AC Input: 200-240 V AC for wide-ranging applications

Built-In Active PFC Function: Enhances power efficiency

Efficiency up to 75%: Reduces energy consumption

IP20 Design: Suitable for indoor installation

Full Protection Plastic Housing: Ensures easy installation and safety

Protections: Short circuit and overload protection for reliability

Cooling by Free Air Convection: Maintains optimal performance

Applications

LED lighting systems

Moving sign applications

Additional Information

Standards Met: EN55015, EN61000-3-2, EN61000-4-2,3,4,5,6,11, EN61347-1, EN61347-2-13, EN61547, FCC Part 15B, UL8750
