MEAN WELL, 48 V Output, 320 W Output Additive 1 to 10V dc, 10V PWM, Resistance

View all LED Drivers

Subtotal (1 unit)*

£72.15

(exc. VAT)

£86.58

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 3 unit(s) ready to ship
  • Plus 3 unit(s) shipping from 09 March 2026
  • Plus 2 unit(s) shipping from 10 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£72.15

*price indicative

RS Stock No.:
149-539
Distrelec Article No.:
303-07-894
Mfr. Part No.:
HLG-320H-48AB
Brand:
MEAN WELL
Find similar products by selecting one or more attributes.
Select all

Brand

MEAN WELL

Output Voltage

48 V

Product Type

LED Driver

Maximum Output Power

320W

Input Voltage

90/305 V

Dimming Operation

Additive 1 to 10V dc, 10V PWM, Resistance

Input Voltage Type

AC/DC

IP Rating

IP65, IP67

Operating Modes

Constant Current/Constant Voltage

Series

HLG-320H

Standards/Approvals

GB17625.1, UL8750, BS EN/EN55024, IP65, BS EN/EN61000-3-2 Class C, CSA C22.2 No. 250.0-08, BS EN/EN55015, BS EN/EN61000-3-3, EAC TP TC 004, EAC TP TC 020, GB19510.1, KC61347-1, J61347-1, J61347-2-13, GB19510.14, BS EN/EN61547, BS EN/EN61000-4-2, BS EN/ES/NZS 61347-1, GB17743, KC61347-2-13, BS EN/ES/NZS 61347-2-13, BS EN/EN55032 (CISPR32) Class B

RoHS Status: Exempt

The MEANWELL AC-DC Single output LED Driver Mix Mode with PFC. It delivers an output of 48Vdc at 6.70A and features dimming with 1-10Vdc 10V PWM resistance. The product is enclosed in a metal housing with an IP65 rating, making it suitable for various applications.

AC-DC Single output LED Driver Mix Mode with PFC

Output of 48Vdc at 6.70A

IP65 rated for protection

Dimming capabilities with 1-10Vdc 10V PWM resistance

Adjustable output current through built-in potentiometer
