Fiamm 12 V, Faston 6.3 Sealed Lead Acid Battery, 7.2 Ah, 65mm x 100 mm
- RS Stock No.:
- 189-1575
- Distrelec Article No.:
- 300-47-211
- Mfr. Part No.:
- 12FGHL28
- Brand:
- Fiamm
Subtotal (1 unit)*
£37.99
(exc. VAT)
£45.59
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 101 unit(s) ready to ship
- Plus 26 unit(s) ready to ship from another location
- Plus 240 unit(s) shipping from 16 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £37.99 |
*price indicative
- RS Stock No.:
- 189-1575
- Distrelec Article No.:
- 300-47-211
- Mfr. Part No.:
- 12FGHL28
- Brand:
- Fiamm
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Fiamm | |
| Battery Capacity | 7.2Ah | |
| Product Type | Sealed Lead Acid Battery | |
| Nominal Voltage | 12V | |
| Construction | VRLA AGM | |
| Flame Resistant | Yes | |
| Designed for Cyclic Application | Yes | |
| Application | Emergency Lighting, Uninterruptable Power Supply, Signalling | |
| Termination Type | Faston 6.3 | |
| Eurobat Classification | 3 to 5 Years | |
| Designed for High Rate Application | No | |
| Maximum Operating Temperature | 25°C | |
| Minimum Operating Temperature | 25°C | |
| Height | 100mm | |
| Width | 65mm | |
| Series | 12FGHL28 | |
| Weight | 2.7kg | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Fiamm | ||
Battery Capacity 7.2Ah | ||
Product Type Sealed Lead Acid Battery | ||
Nominal Voltage 12V | ||
Construction VRLA AGM | ||
Flame Resistant Yes | ||
Designed for Cyclic Application Yes | ||
Application Emergency Lighting, Uninterruptable Power Supply, Signalling | ||
Termination Type Faston 6.3 | ||
Eurobat Classification 3 to 5 Years | ||
Designed for High Rate Application No | ||
Maximum Operating Temperature 25°C | ||
Minimum Operating Temperature 25°C | ||
Height 100mm | ||
Width 65mm | ||
Series 12FGHL28 | ||
Weight 2.7kg | ||
Standards/Approvals No | ||
RoHS Status: Exempt
- COO (Country of Origin):
- VN
FGH Designed For Maximum Performance in Critical Power Applications Such as UPS. The Range is Available In 12V Blocks With A Capacity Range Of 5 - 18AH.
Features
Special lead calcium tin alloy grid, designed to resist corrosion and provide short recharge time
VRLA AGM technology using low resistance high microporous fiberglass separators
Leak resistant post seal, faston, flag and threaded female, terminals with high conductivity and maximum torque resistance
One-way safety relief valves allow gas to escape and prevent the ingress of oxygen
ABS plastic
Installation in any orientation (excluding permanently inverted)
