Riverdi RVA35HI-NUCLEO144A TFT LCD Display Touch Screen, 3.5 in, 320 x 480 pixel
- RS Stock No.:
- 672-199
- Mfr. Part No.:
- RVA35HI-NUCLEO144A
- Brand:
- Riverdi
Subtotal (1 unit)*
£33.81
(exc. VAT)
£40.57
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 8 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £33.81 |
*price indicative
- RS Stock No.:
- 672-199
- Mfr. Part No.:
- RVA35HI-NUCLEO144A
- Brand:
- Riverdi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Riverdi | |
| Product Type | TFT LCD Display | |
| Diagonal Display Size | 3.5in | |
| Interface Type | SPI, RGB | |
| Screen Resolution | 320 x 480 pixel | |
| Current | 50mA | |
| Touch Screen | Yes | |
| Viewing Area Dimensions | 73.44 x 48.96 mm | |
| Touch Screen Type | Capacitive | |
| Backlight Type | 10 LEDs | |
| Minimum Supply Voltage | 2.5V | |
| Maximum Supply Voltage | 3.3V | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Depth | 19.8mm | |
| Standards/Approvals | RoHS Compliant | |
| Width | 93.95mm | |
| Height | 70.45mm | |
| Brightness | 1200cd/m² | |
| Series | STM32 Nucleo 144 | |
| Display Type | TFT | |
| Select all | ||
|---|---|---|
Brand Riverdi | ||
Product Type TFT LCD Display | ||
Diagonal Display Size 3.5in | ||
Interface Type SPI, RGB | ||
Screen Resolution 320 x 480 pixel | ||
Current 50mA | ||
Touch Screen Yes | ||
Viewing Area Dimensions 73.44 x 48.96 mm | ||
Touch Screen Type Capacitive | ||
Backlight Type 10 LEDs | ||
Minimum Supply Voltage 2.5V | ||
Maximum Supply Voltage 3.3V | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Depth 19.8mm | ||
Standards/Approvals RoHS Compliant | ||
Width 93.95mm | ||
Height 70.45mm | ||
Brightness 1200cd/m² | ||
Series STM32 Nucleo 144 | ||
Display Type TFT | ||
- COO (Country of Origin):
- PL
The Riverdi 3.5 inch Nucleo-144 Display Kit is a development-ready solution combining a vibrant 3.5 inch TFT touchscreen with seamless support for STM32 Nucleo-144 boards. It enables fast prototyping of graphical user interfaces in embedded applications. Designed for ease of integration, it includes precise touch input and high-quality visuals. Ideal for engineers building compact HMI systems or interactive control panels.
Optical bonding
MCU and SPI video interface
Industrial PCAP touch panel with I2C interface
