RS PRO Battery Isolator Switch, 100 A
- RS Stock No.:
- 325-4856
- Distrelec Article No.:
- 304-03-194
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£93.36
(exc. VAT)
£112.03
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 16 unit(s) ready to ship
- Plus 3 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 24 | £93.36 |
25 - 99 | £88.79 |
100 - 249 | £83.46 |
250 - 499 | £75.99 |
500 + | £72.16 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£26.81
(exc. VAT)
£32.17
(inc. VAT)
- RS Stock No.:
- 325-4856
- Distrelec Article No.:
- 304-03-194
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Contact Current Rating | 100 A | |
Application | Automotive | |
Depth Behind Panel | 46mm | |
Minimum Operating Temperature | -40°C | |
Operating Temperature Range | -40 → +55°C | |
Voltage Rating DC | 24V | |
Maximum Operating Temperature | +55°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Contact Current Rating 100 A | ||
Application Automotive | ||
Depth Behind Panel 46mm | ||
Minimum Operating Temperature -40°C | ||
Operating Temperature Range -40 → +55°C | ||
Voltage Rating DC 24V | ||
Maximum Operating Temperature +55°C | ||
RS PRO Battery Isolator Switch, 100 A, -40°C → +55°C
This battery isolator switch from RS PRO provides a simple and effective way to disconnect a battery bank from equipment for safety, security or servicing. The switch has a durable metal casing suitable for panel mounting, with a corrosion-resistant chrome finish. It's operated with a key that you can remove in either position. The switch is contact current-rated at 100 A and will operate within a temperature range of -40°C to +55˚C.
This item is part of the tried and tested RS PRO range. The switch complies with the ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards, meaning it won't damage equipment via electrostatic discharge. It's also RoHS compliant, meaning it contains only minimal levels of hazardous substances.
Battery isolator switches of this kind are commonly found in automotive, traction and marine applications. Please note that we don't supply spare keys for security reasons.
This item is part of the tried and tested RS PRO range. The switch complies with the ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards, meaning it won't damage equipment via electrostatic discharge. It's also RoHS compliant, meaning it contains only minimal levels of hazardous substances.
Battery isolator switches of this kind are commonly found in automotive, traction and marine applications. Please note that we don't supply spare keys for security reasons.
Features and Benefits
• Battery isolator switch
• Contact current rating of 100 A
• Nominal voltage rating of 24 V DC
• Maximum operating temperature of +55˚C
• Minimum operating temperature of -40˚C
• Depth behind panel of 46 mm
• Suitable for automotive applications
• Conforms to ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards
• RoHS (Restriction of Hazardous Substances) compliant
• Contact current rating of 100 A
• Nominal voltage rating of 24 V DC
• Maximum operating temperature of +55˚C
• Minimum operating temperature of -40˚C
• Depth behind panel of 46 mm
• Suitable for automotive applications
• Conforms to ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards
• RoHS (Restriction of Hazardous Substances) compliant
RS PRO
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
theyre only given the RS PRO Seal of Approval if were confident of their exceptional quality, which means you can be confident too.
Note
For security reasons spare keys are not available
