TE Connectivity, AMPMODU Shunt Straight Female Red Open Top 2 Way 1 Row 2.54 mm Pitch
- RS Stock No.:
- 718-8548
- Distrelec Article No.:
- 304-63-544
- Mfr. Part No.:
- 382811-9
- Brand:
- TE Connectivity
Subtotal (1 pack of 5 units)*
£1.34
(exc. VAT)
£1.61
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 24 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £0.268 | £1.34 |
*price indicative
- RS Stock No.:
- 718-8548
- Distrelec Article No.:
- 304-63-544
- Mfr. Part No.:
- 382811-9
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Sub Type | Open Top | |
| Product Type | Shunt | |
| Number of Contacts | 2 | |
| Pitch | 2.54mm | |
| Connector Gender | Female | |
| Colour | Red | |
| Number of Rows | 1 | |
| Length | 5.08mm | |
| Series | AMPMODU | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold over Nickel | |
| Width | 2.54mm | |
| Orientation | Straight | |
| Depth | 6.35mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Sub Type Open Top | ||
Product Type Shunt | ||
Number of Contacts 2 | ||
Pitch 2.54mm | ||
Connector Gender Female | ||
Colour Red | ||
Number of Rows 1 | ||
Length 5.08mm | ||
Series AMPMODU | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold over Nickel | ||
Width 2.54mm | ||
Orientation Straight | ||
Depth 6.35mm | ||
TE Connectivity AMPMODU 2 Position Economy Low Profile Shunts
AMPMODU 2 position Economy low profile shunts with a 2.54mm centerline. These AMPMODU economy low profile shunts have an open TOP design with a height of 6.35mm, A One piece contact construction and are stackable. The housings of these AMPMODU shunts are MADE from UL 94V-0 rated black glass filled polyester. There is a choice of contact platings for these AMPMODU economy low profile shunts, please refer to datasheet on our website for details.
2.54mm TE Connectivity AMPMODU™ Range – Style 2 (European)
A wide range of modular interconnects on the industry standard 2.54mm (0.1in ) Grid, addressing applications across all industry sectors. Designed for wire to board or board to board connection, including stacking.
