ABB 4-Pole DIN Rail Isolator Switch -, IP40, IP20, 50A
- RS Stock No.:
- 175-5100
- Mfr. Part No.:
- 2CDD284101R0050 SD204/50
- Brand:
- ABB
Subtotal (1 unit)*
£88.31
(exc. VAT)
£105.97
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £88.31 |
*price indicative
- RS Stock No.:
- 175-5100
- Mfr. Part No.:
- 2CDD284101R0050 SD204/50
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Number of Poles | 4 | |
| Product Type | Isolator Switch | |
| Mount Type | DIN Rail | |
| IP Rating | IP40, IP20 | |
| Electrical Phase | 3 | |
| Handle Colour | Grey | |
| Auxiliary Contacts Available | Yes | |
| Terminal Type | Screw | |
| Switching Current | 50A | |
| Series | SD204 | |
| Switching AC Voltage | 462V ac | |
| Switching DC Voltage | 131V dc | |
| Minimum Operating Temperature | -25°C | |
| Padlock Compatibility | Yes | |
| Maximum Operating Temperature | 55°C | |
| Width | 69mm | |
| Standards/Approvals | CE, VDE, RoHS | |
| Hazardous Area Certification | NO | |
| Depth | 88mm | |
| Length | 70mm | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Number of Poles 4 | ||
Product Type Isolator Switch | ||
Mount Type DIN Rail | ||
IP Rating IP40, IP20 | ||
Electrical Phase 3 | ||
Handle Colour Grey | ||
Auxiliary Contacts Available Yes | ||
Terminal Type Screw | ||
Switching Current 50A | ||
Series SD204 | ||
Switching AC Voltage 462V ac | ||
Switching DC Voltage 131V dc | ||
Minimum Operating Temperature -25°C | ||
Padlock Compatibility Yes | ||
Maximum Operating Temperature 55°C | ||
Width 69mm | ||
Standards/Approvals CE, VDE, RoHS | ||
Hazardous Area Certification NO | ||
Depth 88mm | ||
Length 70mm | ||
The SD 200 extends the proven System pro M compact ® series by a new range of switch disconnectors which provides state-of-the-art safety and comfort. The series is available with 1 to 4 poles with rated currents from 16 to 63 A and provides disconnection properties. With a rated voltage of 253/440 V AC, a rated conditional short-circuit current of 25 kA, terminals with protection from misconnection, a “Real CPI” contact position indication, as well as full compatibility with all MCB accessories, SD 200 is unique in its field of application.
Clear contact position indication in red/green (“Real CPI”)
Highest performance at an increased voltage level
35 mm² cylinder lift terminal with 2 terminal openings
Consistent design to other System pro M DIN rail products
Cross wiring with MCBs or RCDs using busbars PS
Durable device identification due to laser labeling
Captive screws with recessed head
