Vishay, 38 kHz IR Receiver, 30 m Range 2.5 V 5.5V, Lead 2.6 mm Bulk 4-Pin 6.8mm
- RS Stock No.:
- 244-4804
- Mfr. Part No.:
- TSOP39238
- Brand:
- Vishay
Subtotal (1 bag of 2400 units)*
£1,032.00
(exc. VAT)
£1,248.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 05 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2400 + | £0.43 | £1,032.00 |
*price indicative
- RS Stock No.:
- 244-4804
- Mfr. Part No.:
- TSOP39238
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | IR Receiver | |
| Carrier Frequency | 38kHz | |
| Maximum Transmission Distance | 30m | |
| Output Current | 5mA | |
| Number of Pins | 4 | |
| Mount Type | Lead | |
| Range Automatic Gain Control AGC | AGC2 | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 85°C | |
| Package Type | Bulk | |
| Width | 6.8mm | |
| Maximum Supply Voltage | 5.5V | |
| Height | 2.6mm | |
| Standards/Approvals | RoHS | |
| Minimum Supply Voltage | 2.5V | |
| Series | TSOP33 | |
| Supply Current | 3mA | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type IR Receiver | ||
Carrier Frequency 38kHz | ||
Maximum Transmission Distance 30m | ||
Output Current 5mA | ||
Number of Pins 4 | ||
Mount Type Lead | ||
Range Automatic Gain Control AGC AGC2 | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 85°C | ||
Package Type Bulk | ||
Width 6.8mm | ||
Maximum Supply Voltage 5.5V | ||
Height 2.6mm | ||
Standards/Approvals RoHS | ||
Minimum Supply Voltage 2.5V | ||
Series TSOP33 | ||
Supply Current 3mA | ||
Automotive Standard No | ||
The Vishay miniaturized IR receiver modules for infrared remote control systems. Two PIN diodes and a preamplifier are assembled on a lead frame, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to digital circuitry for decoding. This series is optimized to suppress almost all spurious pulses from energy saving lamps like CFLs.
Very low supply current
Photo detector and preamplifier in one package
Internal filter for PCM frequency
Insensitive to supply voltage ripple and noise
Improved immunity against modulated light sources
Two lenses for high sensitivity
