onsemi MC74AC05DG Dual CMOS Inverter, 14-Pin SOIC
- RS Stock No.:
- 186-8579
- Mfr. Part No.:
- MC74AC05DG
- Brand:
- onsemi
Subtotal (1 pack of 25 units)*
£8.625
(exc. VAT)
£10.35
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 25 + | £0.345 | £8.63 |
*price indicative
- RS Stock No.:
- 186-8579
- Mfr. Part No.:
- MC74AC05DG
- Brand:
- onsemi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | onsemi | |
| Logic Function | Inverter | |
| Input Type | TTL | |
| Output Type | Open Drain | |
| Number of Elements per Chip | 2 | |
| Maximum Propagation Delay Time @ Maximum CL | 9 ns @ 50 pF | |
| Maximum High Level Output Current | -24mA | |
| Maximum Low Level Output Current | 24mA | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Pin Count | 14 | |
| Logic Family | AC | |
| Dimensions | 8.75 x 4 x 1.5mm | |
| Height | 1.5mm | |
| Maximum Operating Supply Voltage | 6 V | |
| Minimum Operating Temperature | -40 °C | |
| Width | 4mm | |
| Maximum Operating Temperature | +85 °C | |
| Length | 8.75mm | |
| Propagation Delay Test Condition | 50pF | |
| Minimum Operating Supply Voltage | 2 V | |
Select all | ||
|---|---|---|
Brand onsemi | ||
Logic Function Inverter | ||
Input Type TTL | ||
Output Type Open Drain | ||
Number of Elements per Chip 2 | ||
Maximum Propagation Delay Time @ Maximum CL 9 ns @ 50 pF | ||
Maximum High Level Output Current -24mA | ||
Maximum Low Level Output Current 24mA | ||
Mounting Type Surface Mount | ||
Package Type SOIC | ||
Pin Count 14 | ||
Logic Family AC | ||
Dimensions 8.75 x 4 x 1.5mm | ||
Height 1.5mm | ||
Maximum Operating Supply Voltage 6 V | ||
Minimum Operating Temperature -40 °C | ||
Width 4mm | ||
Maximum Operating Temperature +85 °C | ||
Length 8.75mm | ||
Propagation Delay Test Condition 50pF | ||
Minimum Operating Supply Voltage 2 V | ||
MC74AC Family, ON Semiconductor
The MC74AC/ACT05 is identical in pinout to the LS05. The device inputs are compatible with standard CMOS outputs, with pullup resistors, they are compatible with TTL outputs.
Outputs Source/Sink 24 mA
ACT05 Has TTL Compatible Inputs
ACT05 Has TTL Compatible Inputs
