Phoenix Contact, 1068 IP67 PCB Mount 4P Power Connector Socket, Rated At 4A, 50 V ac, 60 V dc
- RS Stock No.:
- 226-5957
- Mfr. Part No.:
- 1068454
- Brand:
- Phoenix Contact
Subtotal (1 pack of 100 units)*
£443.90
(exc. VAT)
£532.70
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
100 + | £4.439 | £443.90 |
*price indicative
- RS Stock No.:
- 226-5957
- Mfr. Part No.:
- 1068454
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Current Rating | 4A | |
Plug/Socket | Socket | |
Pole Format | 4P | |
Voltage Rating | 50 V ac, 60 V dc | |
Mounting Type | PCB Mount | |
Body Orientation | Straight | |
Series | 1068 | |
IP Rating | IP67 | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Current Rating 4A | ||
Plug/Socket Socket | ||
Pole Format 4P | ||
Voltage Rating 50 V ac, 60 V dc | ||
Mounting Type PCB Mount | ||
Body Orientation Straight | ||
Series 1068 | ||
IP Rating IP67 | ||
- COO (Country of Origin):
- DE
Flush-type connector
The Phoenix Contact flush-type connector has a ethernet/PROFINET CAT5 (100 Mbps) and 4-position. Socket body orientation is straight and thread size is M8.Mounting type PCB mount.
For compact devices transmit high power in a confined space
Easy-to-install, optimized XL housing contour with wrench size 19
Mechanical tightening limitation for long-term-stable gasket
Pre-assembled with litz wires for immediate use
Customer-specific assemblies and litz wire lengths available
Sealed on the litz wire side for optimum leak-tightness
For high transmission safety shield connection to the housing with optional EMC nut
Easy-to-install, optimized XL housing contour with wrench size 19
Mechanical tightening limitation for long-term-stable gasket
Pre-assembled with litz wires for immediate use
Customer-specific assemblies and litz wire lengths available
Sealed on the litz wire side for optimum leak-tightness
For high transmission safety shield connection to the housing with optional EMC nut
