binder Circular Connector, 3 Contacts, Cable Mount, M16 Connector, Plug, Female, IP67, 423 Series
- RS Stock No.:
- 734-5158
- Distrelec Article No.:
- 304-09-363
- Mfr. Part No.:
- 99-5106-40-03
- Brand:
- binder
Save 30% when you buy 500 units
Subtotal (1 unit)*
£12.64
(exc. VAT)
£15.17
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 48 unit(s) ready to ship
- Plus 29 unit(s) ready to ship from another location
- Plus 10 unit(s) shipping from 08 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 49 | £12.64 |
50 - 99 | £11.71 |
100 - 249 | £10.75 |
250 - 499 | £9.77 |
500 + | £8.83 |
*price indicative
- RS Stock No.:
- 734-5158
- Distrelec Article No.:
- 304-09-363
- Mfr. Part No.:
- 99-5106-40-03
- Brand:
- binder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | binder | |
Number of Contacts | 3 | |
Mounting Type | Cable Mount | |
Connector Size | M16 | |
Plug/Socket | Plug | |
Contact Gender | Female | |
Termination Method | Solder | |
IP Rating | IP67 | |
Current Rating | 7.0A | |
Body Orientation | Straight | |
Series | 423 | |
Voltage Rating | 250.0 V | |
Shell Size | 18.5 | |
Mating Type | Screw On | |
Housing Material | Metal | |
Contact Plating | Gold | |
Maximum Operating Temperature | +95°C | |
Contact Material | Bronze | |
Minimum Operating Temperature | -30°C | |
Select all | ||
---|---|---|
Brand binder | ||
Number of Contacts 3 | ||
Mounting Type Cable Mount | ||
Connector Size M16 | ||
Plug/Socket Plug | ||
Contact Gender Female | ||
Termination Method Solder | ||
IP Rating IP67 | ||
Current Rating 7.0A | ||
Body Orientation Straight | ||
Series 423 | ||
Voltage Rating 250.0 V | ||
Shell Size 18.5 | ||
Mating Type Screw On | ||
Housing Material Metal | ||
Contact Plating Gold | ||
Maximum Operating Temperature +95°C | ||
Contact Material Bronze | ||
Minimum Operating Temperature -30°C | ||
- COO (Country of Origin):
- DE
Binder 423 Series Miniature M16 Connector
Binder Series 423 connectors are a high-quality cylindrical connector series with M16 threaded locking sleeves, the circular connectors provide excellent EMI shielding via a shielding ring or cable clamp and are IP67 rated in the mated position. Durable and rugged miniature connectors, these Series 423 connectors are suitable for many severe industrial and commercial applications and have current rating ranges from 7 A to 1A per contact, dependant on the number of contacts per connector.
Rugged metal shells
Straight or right-angle cable connector
Right-angle cable connectors adjustable in 4 radial positions
Excellent 360° EMI shielding and IP67
Internal strain relief
Precision metal construction
Easy assembly
Straight or right-angle cable connector
Right-angle cable connectors adjustable in 4 radial positions
Excellent 360° EMI shielding and IP67
Internal strain relief
Precision metal construction
Easy assembly
