SICK Connector, 5 Contacts, Screw, M12 Connector, Plug, Male, IP69K, YM12ES5 Series

RS Stock No.:: 285-1566
Mfr. Part No.:: YM12ES5-0075S5586A / 2097336
Brand:: SICK

Subtotal (1 unit)*

£108.92

(exc. VAT)

£130.70

(inc. VAT)

FREE delivery for orders over £60.00

Stocked by manufacturer

Ready to ship from 09 September 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£108.92

*price indicative

RS Stock No.:: 285-1566
Mfr. Part No.:: YM12ES5-0075S5586A / 2097336
Brand:: SICK

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	SICK
	Number of Contacts	5
	Product Type	Connector
	Mount Type	Screw
	Connector Size	M12
	Current	4A
	Plug/Socket	Plug
	Contact Gender	Male
	IP Rating	IP69K
	Series	YM12ES5
	Orientation	Straight
	Voltage	60.0V
	Coding	A
	Termination Type	Screw
	Mating Type	Plug-In
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Housing Material	Stainless Steel
	Standards/Approvals	RoHS
	Contact Material	Stainless Steel

	Select all
	Brand SICK
	Number of Contacts 5
	Product Type Connector
	Mount Type Screw
	Connector Size M12
	Current 4A
	Plug/Socket Plug
	Contact Gender Male
	IP Rating IP69K
	Series YM12ES5
	Orientation Straight
	Voltage 60.0V
	Coding A
	Termination Type Screw
	Mating Type Plug-In
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Housing Material Stainless Steel
	Standards/Approvals RoHS
	Contact Material Stainless Steel

Datasheet - YM12ES5-0075S5586A

COO (Country of Origin):: DE

Overview

The Connectors from field attachable connectors family provides a female connector, with a M12 specification and 5 pins arranged in a straight configuration at Head A with A coded, utilizes screw type terminals for a reliable connection. Constructed with stainless steel (V4A/1.4404) material.

The connectors accommodate cables with a permitted diameter ranging from 5.5 mm to 8.6 mm. They can handle a current loading of up to 4 A. The connectors are designed with an enclosure rating of IP69K.
