RS PRO Circular Connector, 3 Contacts, Cable Mount, Plug and Socket, Male and Female Contacts, IP67
- RS Stock No.:
- 250-6043
- Brand:
- RS PRO
67 In stock - FREE next working day delivery available
Added
Price 1 Pair
£11.85
(exc. VAT)
£14.22
(inc. VAT)
| Pair(s) | Per Pair |
| 1 - 4 | £11.85 |
| 5 - 9 | £11.60 |
| 10 - 24 | £11.37 |
| 25 + | £10.80 |
- RS Stock No.:
- 250-6043
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
RS PRO 2 Pole 5A Cable Mount Circular Connector Set (SY11)
The RS PRO cable mount circular connector set offers a reliable way to create secure wire connections in industrial and automated applications.
Featuring separate male and female circular connectors with a quick connecting bayonet fitting the RS PRO circular connector set is easy to install and includes numbered receptacles reducing soldering errors and saving time and rework.
Constructed from a fire-resistant Polycarbonate and Nylon shell protecting Gold Plated Brass contacts and an Ingress Protection rating of IP67 the RS PRO industrial connector is designed for use in harsh and heavy-duty environments.
Kit Includes
1 x Male circular connector: 43.5mm length
1 x Female circular connector: 44mm length
Features and benefits
- IP67 rating
- Cable mount
- Bayonet coupling
- Maximum wire size of <0.75mm (18AWG)
- Cable outer diameter range of 4 to 6mm
- Temperature range of -40 to 85°C
Suitable Applications
- Factory and Industrial Automation
- Manufacturing
- Process Control
- Industrial networking
Why RS PRO?
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards; they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 3 |
| Mounting Type | Cable Mount |
| Connector Size | Standard |
| Plug/Socket | Plug, Socket |
| Contact Gender | Female, Male |
| Termination Method | Solder |
| IP Rating | IP67 |
| Current Rating | 5A |
| Body Orientation | Straight |
| Series | SY11 |
| Voltage Rating | 180 V |
| Mating Type | Bayonet |
| Pole Format | 3P |
