Bulgin Circular Connector, 4 Contacts, Panel Mount, M16 Connector, Socket, Female, IP67, Buccaneer M16 Series
- RS Stock No.:
- 208-8180
- Mfr. Part No.:
- PXMBNI16RPF04ASCM16
- Brand:
- Bulgin
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£24.62
(exc. VAT)
£29.54
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £24.62 |
| 10 + | £23.93 |
*price indicative
- RS Stock No.:
- 208-8180
- Mfr. Part No.:
- PXMBNI16RPF04ASCM16
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Number of Contacts | 4 | |
| Product Type | Circular Connector | |
| Mount Type | Panel Mount | |
| Connector Size | M16 | |
| Current | 7A | |
| Plug/Socket | Socket | |
| Contact Gender | Female | |
| IP Rating | IP67 | |
| Series | Buccaneer M16 | |
| Orientation | Straight | |
| Voltage | 250V | |
| Coding | A | |
| Mating Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Termination Type | Solder | |
| Shell Size | 20 mm | |
| Maximum Operating Temperature | 80°C | |
| Housing Material | Nickel Plated Brass | |
| Standards/Approvals | DIN EN 61076-2-106 | |
| Contact Plating | Gold Plated | |
| Contact Material | Brass, Phosphor Bronze | |
| Select all | ||
|---|---|---|
Brand Bulgin | ||
Number of Contacts 4 | ||
Product Type Circular Connector | ||
Mount Type Panel Mount | ||
Connector Size M16 | ||
Current 7A | ||
Plug/Socket Socket | ||
Contact Gender Female | ||
IP Rating IP67 | ||
Series Buccaneer M16 | ||
Orientation Straight | ||
Voltage 250V | ||
Coding A | ||
Mating Type Screw | ||
Minimum Operating Temperature -25°C | ||
Termination Type Solder | ||
Shell Size 20 mm | ||
Maximum Operating Temperature 80°C | ||
Housing Material Nickel Plated Brass | ||
Standards/Approvals DIN EN 61076-2-106 | ||
Contact Plating Gold Plated | ||
Contact Material Brass, Phosphor Bronze | ||
- COO (Country of Origin):
- CN
The Bulgin M16 series Circular Automation Connector comes With excellent EMI shielding and an environmental protection rating of IP67. It is an ideal solution for ensuring that power and signal connections are not compromised in harsh environments and ind
Solder termination
Rear panel mount M16
