Bulgin Circular Connector, 5 Contacts, Panel Mount, M16 Connector, Socket, Female, IP67, Buccaneer M16 Series
- RS Stock No.:
- 144-6897
- Mfr. Part No.:
- PXMBNI16FBF05ASCPG9
- Brand:
- Bulgin
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 144-6897
- Mfr. Part No.:
- PXMBNI16FBF05ASCPG9
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Number of Contacts | 5 | |
| Product Type | Circular Connector | |
| Mount Type | Panel Mount | |
| Current | 6A | |
| Connector Size | M16 | |
| Plug/Socket | Socket | |
| Contact Gender | Female | |
| IP Rating | IP67 | |
| Orientation | Straight | |
| Series | Buccaneer M16 | |
| Coding | A | |
| Voltage | 250.0V | |
| Shell Size | 18.5 | |
| Termination Type | Solder | |
| Mating Type | Threaded | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 80°C | |
| Housing Material | Nickel | |
| Standards/Approvals | No | |
| Pole Format | 5 | |
| Contact Plating | Gold | |
| Contact Material | Bronze | |
| Select all | ||
|---|---|---|
Brand Bulgin | ||
Number of Contacts 5 | ||
Product Type Circular Connector | ||
Mount Type Panel Mount | ||
Current 6A | ||
Connector Size M16 | ||
Plug/Socket Socket | ||
Contact Gender Female | ||
IP Rating IP67 | ||
Orientation Straight | ||
Series Buccaneer M16 | ||
Coding A | ||
Voltage 250.0V | ||
Shell Size 18.5 | ||
Termination Type Solder | ||
Mating Type Threaded | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 80°C | ||
Housing Material Nickel | ||
Standards/Approvals No | ||
Pole Format 5 | ||
Contact Plating Gold | ||
Contact Material Bronze | ||
- COO (Country of Origin):
- CN
With a rugged metal housing and environmental protection rating of IP67 when mated, Bulgin's robust M16 circular DIN connector range is an ideal solution for ensuring that power and signal connections are not compromised in harsh environments and industrial applications.
Screw locking compliant with DIN EN 61076-2-106
IP67 degree of protection
Robust metal connector
Excellent EMI shielding
Pole variants from 3 - 12
M16 Flex Body Female
3, 4, 5, 6, 8 and 12 poles
Solder termination
Metal Flex Body
Mates with Flex Inline Body and panel mount connectors
