Bulgin Circular Connector, 8 Contacts, In-Line, M16 Connector, Plug, Male, IP67, Buccaneer M16 Series
- RS Stock No.:
- 144-6893
- Mfr. Part No.:
- PXMBNI16FIM08ASC
- Brand:
- Bulgin
Subtotal (1 unit)*
£48.79
(exc. VAT)
£58.55
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 14 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £48.79 |
*price indicative
- RS Stock No.:
- 144-6893
- Mfr. Part No.:
- PXMBNI16FIM08ASC
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Product Type | Circular Connector | |
| Number of Contacts | 8 | |
| Mount Type | In-Line | |
| Current | 5A | |
| Connector Size | M16 | |
| Plug/Socket | Plug | |
| Contact Gender | Male | |
| IP Rating | IP67 | |
| Series | Buccaneer M16 | |
| Orientation | Straight | |
| Coding | A | |
| Voltage | 60.0V | |
| Mating Type | Threaded | |
| Termination Type | Solder | |
| Shell Size | 18.5 | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 80°C | |
| Housing Material | Nickel | |
| Standards/Approvals | No | |
| Pole Format | 8 | |
| Contact Plating | Gold | |
| Contact Material | Brass | |
| Select all | ||
|---|---|---|
Brand Bulgin | ||
Product Type Circular Connector | ||
Number of Contacts 8 | ||
Mount Type In-Line | ||
Current 5A | ||
Connector Size M16 | ||
Plug/Socket Plug | ||
Contact Gender Male | ||
IP Rating IP67 | ||
Series Buccaneer M16 | ||
Orientation Straight | ||
Coding A | ||
Voltage 60.0V | ||
Mating Type Threaded | ||
Termination Type Solder | ||
Shell Size 18.5 | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 80°C | ||
Housing Material Nickel | ||
Standards/Approvals No | ||
Pole Format 8 | ||
Contact Plating Gold | ||
Contact Material Brass | ||
- COO (Country of Origin):
- CN
With a rugged metal housing and environmental protection rating of IP67 when mated, Bulgin's robust M16 circular DIN connector range is an ideal solution for ensuring that power and signal connections are not compromised in harsh environments and industrial applications.
Screw locking compliant with DIN EN 61076-2-106
IP67 degree of protection
Robust metal connector
Excellent EMI shielding
Pole variants from 3 - 12
M16 Flex Inline Body Male
3, 4, 5, 6, 8 and 12 poles
Solder termination
Metal Flex Inline Body
Mates with Flex Body and panel mount connectors
