Infineon IKB40N65EH5ATMA1, Type N-Channel IGBT Single Transistor IC, 74 A 650 V, 3-Pin TO-247, Surface

View all IGBTs
Bulk discount available

Subtotal (1 pack of 2 units)*

£6.12

(exc. VAT)

£7.34

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 31 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 - 18£3.06£6.12
20 - 48£2.76£5.52
50 - 98£2.57£5.14
100 - 198£2.385£4.77
200 +£2.23£4.46

*price indicative

Packaging Options:
RS Stock No.:
215-6653
Mfr. Part No.:
IKB40N65EH5ATMA1
Brand:
Infineon
Find similar products by selecting one or more attributes.
Select all

Brand

Infineon

Maximum Continuous Collector Current Ic

74A

Product Type

IGBT Single Transistor IC

Maximum Collector Emitter Voltage Vceo

650V

Maximum Power Dissipation Pd

333W

Package Type

TO-247

Mount Type

Surface

Channel Type

Type N

Pin Count

3

Minimum Operating Temperature

-40°C

Maximum Gate Emitter Voltage VGEO

±30 V

Maximum Collector Emitter Saturation Voltage VceSAT

1.65V

Maximum Operating Temperature

175°C

Standards/Approvals

No

Series

High Speed Fifth Generation

Automotive Standard

No

The Infineon high speed switching insulated-gate bipolar transistor copacked with full rated current rapid 1 antiparallel diode.

High Efficiency

Low Switching Losses

Increased Reliability

Low Electromagnetic Interference
