Samtec 20-Way PCB Header Male for Through Hole, 2 Row
- RS Stock No.:
- 196-9791
- Mfr. Part No.:
- EHT-110-01-F-D
- Brand:
- Samtec
Bulk discount available
Subtotal (1 tube of 16 units)*
£64.112
(exc. VAT)
£76.928
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 16 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 16 - 64 | £4.007 | £64.11 |
| 80 - 144 | £3.834 | £61.34 |
| 160 - 304 | £3.465 | £55.44 |
| 320 + | £3.004 | £48.06 |
*price indicative
- RS Stock No.:
- 196-9791
- Mfr. Part No.:
- EHT-110-01-F-D
- Brand:
- Samtec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Samtec | |
| Product Type | PCB Header | |
| Number of Contacts | 20 | |
| Number of Rows | 2 | |
| Pitch | 2mm | |
| Shrouded/Unshrouded | Shrouded | |
| Connector Gender | Male | |
| Mount Type | Through Hole | |
| Orientation | Straight | |
| Contact Plating | Gold, Tin | |
| Series | EHT | |
| Termination Type | IDC | |
| Minimum Operating Temperature | -55°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | No | |
| Contact Material | Phosphor Bronze | |
| Housing Material | Liquid Crystal Polymer | |
| Select all | ||
|---|---|---|
Brand Samtec | ||
Product Type PCB Header | ||
Number of Contacts 20 | ||
Number of Rows 2 | ||
Pitch 2mm | ||
Shrouded/Unshrouded Shrouded | ||
Connector Gender Male | ||
Mount Type Through Hole | ||
Orientation Straight | ||
Contact Plating Gold, Tin | ||
Series EHT | ||
Termination Type IDC | ||
Minimum Operating Temperature -55°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals No | ||
Contact Material Phosphor Bronze | ||
Housing Material Liquid Crystal Polymer | ||
The Samtec EHT-110-01-F-D is a shrouded IDC ejector header. This header has polarization notch and it also has optional caps to lock cable. Its terminal is made up of phosphor bronze.
Insulator material: black liquid crystal polymer
Operating temperature range:-55°C to +125°C
SMT lead coplanarity:0.10mm max
