HARWIN 10-Way IDC Connector Socket for Cable Mount, 2-Row
- RS Stock No.:
- 161-3530
- Mfr. Part No.:
- M50-9100542
- Brand:
- HARWIN
Bulk discount available
Subtotal (1 unit)*
£8.69
(exc. VAT)
£10.43
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 85 unit(s) ready to ship
- Plus 35 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £8.69 |
| 10 - 49 | £7.95 |
| 50 - 99 | £7.31 |
| 100 - 249 | £6.77 |
| 250 + | £6.33 |
*price indicative
- RS Stock No.:
- 161-3530
- Mfr. Part No.:
- M50-9100542
- Brand:
- HARWIN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARWIN | |
| Number of Contacts | 10 | |
| Number of Rows | 2 | |
| Gender | Female | |
| Pitch | 1.27mm | |
| Mounting Type | Cable Mount | |
| Body Orientation | Straight | |
| Termination Method | Solder | |
| Current Rating | 500mA | |
| Contact Plating | Gold, Tin over Nickel | |
| Series | Archer M50 | |
| Minimum Operating Temperature | -20.0°C | |
| Maximum Operating Temperature | 105.0°C | |
| Voltage Rating | 300.0 V ac | |
| Contact Material | Phosphor Bronze | |
| Housing Material | PBT | |
Select all | ||
|---|---|---|
Brand HARWIN | ||
Number of Contacts 10 | ||
Number of Rows 2 | ||
Gender Female | ||
Pitch 1.27mm | ||
Mounting Type Cable Mount | ||
Body Orientation Straight | ||
Termination Method Solder | ||
Current Rating 500mA | ||
Contact Plating Gold, Tin over Nickel | ||
Series Archer M50 | ||
Minimum Operating Temperature -20.0°C | ||
Maximum Operating Temperature 105.0°C | ||
Voltage Rating 300.0 V ac | ||
Contact Material Phosphor Bronze | ||
Housing Material PBT | ||
- COO (Country of Origin):
- CN
Female-to-Female IDC Cable Assembly (Socket to Socket), 150mm cable (0.635mm pitch ribbon) - 10 contacts (5+5).
Manufactured with M50-3300542 IDC connectors.
Manufactured with M50-3300542 IDC connectors.
