Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Connector A | NPT 3/8 Male | |
Connector B | 3/8 in Male | |
Overall Length | 2m | |
Inside Diameter | 6.6mm | |
Maximum Operating Pressure | 1500bar | |
Outside Diameter | 13.7mm | |
Inner Hose Material | Polyester | |
Cover Material | PU | |
Connector A - Angle | Straight | |
Connector B - Thread Size | 3/8in | |
Connector A - Thread Standard | NPT | |
Connector B - Gender | Male | |
Connector A - Thread Size | 3/8in | |
Maximum Operating Temperature | 100°C | |
Connector A - Gender | Male | |
Minimum Operating Temperature | -40°C | |
Connector B - Angle | Straight | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Connector A NPT 3/8 Male | ||
Connector B 3/8 in Male | ||
Overall Length 2m | ||
Inside Diameter 6.6mm | ||
Maximum Operating Pressure 1500bar | ||
Outside Diameter 13.7mm | ||
Inner Hose Material Polyester | ||
Cover Material PU | ||
Connector A - Angle Straight | ||
Connector B - Thread Size 3/8in | ||
Connector A - Thread Standard NPT | ||
Connector B - Gender Male | ||
Connector A - Thread Size 3/8in | ||
Maximum Operating Temperature 100°C | ||
Connector A - Gender Male | ||
Minimum Operating Temperature -40°C | ||
Connector B - Angle Straight | ||
RoHS Status: Exempt
- COO (Country of Origin):
- IT
RS PRO Hydraulic Hose Assembly, 700bar Max Pressure
This RS PRO Hydraulic Hose Assembly is designed for very high-pressure hydraulic systems, offering excellent durability and flexibility. It is compatible with hydraulic oils, lubricants, fuel, and mineral oils, as well as most ester phosphates. Ideal for industrial tools, locking systems, pumps, power units, and rescue equipment, this hose ensures reliable performance in demanding environments.
Features and Benefits
Meets DMQ approved specifications: Impulse tested at 110% of declared dynamic pressure for reliability
DMQ approved fittings: Ensures secure and leak-free connections
Pipe marking compliance: Adheres to current regulations for safety and traceability
Anti-tear and anti-puncture sheath: Prevents leakage of pressurized oil
Length 2m: Available in different lengths for various applications
Protective sheath: Offers additional durability and protection
Polyester elastomer construction: Coated with black polyurethane for non-micro perforation
Reinforced with aramidic and steel braids: Provides a compact, light, and flexible design
Anti-abrasion cover: Resists over 200,000 cycles according to ISO 6945
Temperature range: Operates effectively from -40°C to +100°C
U.V. Resistance: Certified according to EN13758-1 for outdoor use
MSHA approval: Suitable for mining applications
Complies with UN-EN 1501-1, EN 982, EN 3457: Meets key industry standards
DMQ approved fittings: Ensures secure and leak-free connections
Pipe marking compliance: Adheres to current regulations for safety and traceability
Anti-tear and anti-puncture sheath: Prevents leakage of pressurized oil
Length 2m: Available in different lengths for various applications
Protective sheath: Offers additional durability and protection
Polyester elastomer construction: Coated with black polyurethane for non-micro perforation
Reinforced with aramidic and steel braids: Provides a compact, light, and flexible design
Anti-abrasion cover: Resists over 200,000 cycles according to ISO 6945
Temperature range: Operates effectively from -40°C to +100°C
U.V. Resistance: Certified according to EN13758-1 for outdoor use
MSHA approval: Suitable for mining applications
Complies with UN-EN 1501-1, EN 982, EN 3457: Meets key industry standards
Applications
This hydraulic hose assembly is typically used in industrial tools, locking systems, pumps, power units, filters, cylinders, industrial vehicles, hydraulic circuits, and rescue equipment such as those used by fire brigades.
Additional Information
The hose features a 36mm thick nylon mesh anti-diffusion sleeve, specially treated to resist abrasion and contain pinhole occurrences at high pressure. It is available in black and complies with multiple industry standards, ensuring safety and performance in various applications.
