Lapp Green/Yellow 2.5 mm² Hook Up Wire, 14 AWG, 100m, PVC Insulation
- RS Stock No.:
- 724-4288
- Mfr. Part No.:
- 4160500
- Brand:
- Lapp
74 In stock - FREE next working day delivery available
14 available from Europe for delivery within 2 working day(s).
Price 1 Reel of 100 Metre(s)
£157.82
(exc. VAT)
£189.38
(inc. VAT)
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 - 24 | £157.82 | £1.578 |
| 25 - 49 | £149.92 | £1.499 |
| 50 + | £142.03 | £1.42 |
*price indicative
- RS Stock No.:
- 724-4288
- Mfr. Part No.:
- 4160500
- Brand:
- Lapp
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
LAPP Green/Yellow Hook-Up Wire, 100m Length, 2.5mm² CSA - 4160500
Use this hook-up wire from LAPP to complete the internal wiring in your appliances. It delivers reliable electrical connections, even in demanding conditions, thanks to its corrosion-resistant tinned copper conductor material. As it has a single stranded conductor core, you can bend the cable to fit your application's shape without damaging the wire or losing conductivity. Flame-retardant and oil-resistant PVC insulation is on hand to protect the cable from common industrial hazards.
Features & Benefits
• 600V voltage rating for use with larger light industrial applications
• Operating temperature range between -40°C and +70°C for use in harsh and variable environments
• Distinctive green and yellow sheath makes the cable easy to identify in busy control cabinets
• Operating temperature range between -40°C and +70°C for use in harsh and variable environments
• Distinctive green and yellow sheath makes the cable easy to identify in busy control cabinets
Applications
• Building security industry
• Internal device wiring
• Refrigerators and freezers
• Internal device wiring
• Refrigerators and freezers
What's meant by a stranded core cable and what benefits does it have?
This cable has a stranded core, meaning it contains several strands of conductive metal looped around each other to form a single wire. Because the strands are slim, you can bend and reshape stranded cables without the risk of losing their high conductivity.
Specifications
Attribute | Value |
|---|---|
| Cross Sectional Area | 2.5 mm² |
| Sheath Colour | Green/Yellow |
| American Wire Gauge | 14 AWG |
| Cable Shape | Single Core |
| Length | 100m |
| Insulation Material | PVC |
| Voltage Rating | 600 V |
| Outer Diameter | 3.7mm |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -40°C |
| CPR Certification | Eca |
| Conductor Material | Tinned Copper |
| Wire Style | UL1015 |
| Standards Met | CSA, UL |
| Resistant To | Oils |
