Alpha Wire Hook-up Wire TEFLON Series Grey 0.62 mm² PTFE Equipment Wire, 20 AWG, 19/0.20 mm, 30m, PTFE Insulation, 5856
- RS Stock No.:
- 177-1264
- Distrelec Article No.:
- 304-21-477
- Mfr. Part No.:
- 5856 SL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£71.36
(exc. VAT)
£85.63
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 10 unit(s) ready to ship
- Plus 8 unit(s) shipping from 03 February 2026
- Plus 9 unit(s) shipping from 24 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £71.36 | £2.379 |
*price indicative
- RS Stock No.:
- 177-1264
- Distrelec Article No.:
- 304-21-477
- Mfr. Part No.:
- 5856 SL005
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 0.62 mm² | |
| Sheath Colour | Grey | |
| American Wire Gauge | 20 AWG | |
| Cable Shape | Single Core | |
| Core Strands | 19/0.20 mm | |
| Length | 30m | |
| Insulation Material | PTFE | |
| Outer Diameter | 1.47mm | |
| Voltage Rating | 600 V | |
| Minimum Operating Temperature | -60°C | |
| Maximum Operating Temperature | +200°C | |
| Conductor Material | Silver Plated Copper | |
| Standards Met | MIL-W-16878/4, NEMA HP-EXBBB, UL1213, VW-1 | |
| Wire Style | UL1213 | |
| Cable Type | High Temperature | |
| Series | Hook-up Wire TEFLON | |
| Tri-rated | No | |
| Shield Type | Unshielded | |
| Insulation Wall Thickness | 0.3mm | |
| Hook Up Wire Type | High Temperature | |
| Resistant To | Chemicals, Oils, Solvents | |
| Number of Strands | 19 | |
| Size of Strands | 0.2 mm | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 0.62 mm² | ||
Sheath Colour Grey | ||
American Wire Gauge 20 AWG | ||
Cable Shape Single Core | ||
Core Strands 19/0.20 mm | ||
Length 30m | ||
Insulation Material PTFE | ||
Outer Diameter 1.47mm | ||
Voltage Rating 600 V | ||
Minimum Operating Temperature -60°C | ||
Maximum Operating Temperature +200°C | ||
Conductor Material Silver Plated Copper | ||
Standards Met MIL-W-16878/4, NEMA HP-EXBBB, UL1213, VW-1 | ||
Wire Style UL1213 | ||
Cable Type High Temperature | ||
Series Hook-up Wire TEFLON | ||
Tri-rated No | ||
Shield Type Unshielded | ||
Insulation Wall Thickness 0.3mm | ||
Hook Up Wire Type High Temperature | ||
Resistant To Chemicals, Oils, Solvents | ||
Number of Strands 19 | ||
Size of Strands 0.2 mm | ||
Belden Hook-up Wire TEFLON Series PTFE Equipment Wire, 30m Length, 0.62 mm² Cross Sectional Area - 5856 SL005
This PTFE equipment wire is designed for high-temperature applications, featuring a single core construction with a grey sheath. With a cross-sectional area of 0.62 mm² and a length of 30m, it is optimised for use in environments where reliability and resistance to extreme conditions are paramount.
Features & Benefits
• High-temperature range from -60°C to +200°C enables versatility
• Silver-plated copper wire enhances conductivity and performance
• UL1213 compliant wire assures safety standards adherence
• Chemical resistant wire provides durability in harsh environments
• 20 AWG high-temperature wire accommodates various industrial applications
• Unshielded design facilitates easy installation and flexibility
• Silver-plated copper wire enhances conductivity and performance
• UL1213 compliant wire assures safety standards adherence
• Chemical resistant wire provides durability in harsh environments
• 20 AWG high-temperature wire accommodates various industrial applications
• Unshielded design facilitates easy installation and flexibility
Applications
• Used for connecting electrical components in automation systems
• Ideal for wiring in electrical and mechanical equipment
• Suitable for requiring chemical resistance
• Employed in high-voltage systems where 600V insulation is essential
• Ideal for wiring in electrical and mechanical equipment
• Suitable for requiring chemical resistance
• Employed in high-voltage systems where 600V insulation is essential
What makes this wire suitable for high-temperature applications?
The wire is constructed with PTFE insulation, allowing it to operate effectively within a temperature range of -60°C to +200°C, making it suitable for various high-temperature environments.
How does the silver plating contribute to performance?
The silver plating on the copper wire significantly improves electrical conductivity, resulting in enhanced performance and reliability in transmitting signals through automated systems and machinery.
Can this wire be used in outdoor applications?
While primarily designed for internal wiring, its chemical resistance makes it suitable for specific outdoor applications. However, proper measures should be taken to protect it from UV exposure and physical damage.
