Alpha Wire Yellow 1.3 mm² Hook Up Wire, 16 AWG, 26/0.25 mm, 30m, PVC Insulation, 3057 YL005
- RS Stock No.:
- 333-436
- Mfr. Part No.:
- 3057 YL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£27.01
(exc. VAT)
£32.41
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 5 unit(s) ready to ship
- Plus 2 unit(s) ready to ship from another location
- Plus 12 unit(s) shipping from 21 July 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £27.01 | £0.90 |
*price indicative
- RS Stock No.:
- 333-436
- Mfr. Part No.:
- 3057 YL005
- Brand:
- Alpha Wire
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 1.3 mm² | |
| Sheath Colour | Yellow | |
| Cable Shape | Single Core | |
| American Wire Gauge | 16 AWG | |
| Core Strands | 26/0.25 mm | |
| Length | 30m | |
| Insulation Material | PVC | |
| Outer Diameter | 2.34mm | |
| Voltage Rating | 300 V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +105°C | |
| Conductor Material | Copper | |
| Standards Met | UL Listed | |
| Wire Style | UL1007 | |
| Fire Behaviour | Flame Retardant | |
| Insulation Wall Thickness | 0.4mm | |
| Size of Strands | 0.25 mm | |
| Number of Strands | 26 | |
Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 1.3 mm² | ||
Sheath Colour Yellow | ||
Cable Shape Single Core | ||
American Wire Gauge 16 AWG | ||
Core Strands 26/0.25 mm | ||
Length 30m | ||
Insulation Material PVC | ||
Outer Diameter 2.34mm | ||
Voltage Rating 300 V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +105°C | ||
Conductor Material Copper | ||
Standards Met UL Listed | ||
Wire Style UL1007 | ||
Fire Behaviour Flame Retardant | ||
Insulation Wall Thickness 0.4mm | ||
Size of Strands 0.25 mm | ||
Number of Strands 26 | ||
