HARTING 930 Range Heavy Duty Power Connector Hood 2, 32B
- RS Stock No.:
- 844-3146
- Mfr. Part No.:
- 09300320423
- Brand:
- HARTING
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£80.96
(exc. VAT)
£97.15
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 2 unit(s) ready to ship
- Plus 2 unit(s) shipping from 17 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £80.96 |
| 10 - 24 | £77.71 |
| 25 + | £74.48 |
*price indicative
- RS Stock No.:
- 844-3146
- Mfr. Part No.:
- 09300320423
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Product Type | Heavy Duty Power Connector Hood | |
| Locking Type | Double Lever | |
| Series | 930 | |
| Sub Type | Connector Hood | |
| Manufacturer Size Code | 32B | |
| Body Material | Die Cast Aluminium | |
| IP Rating | IP65 | |
| Cable Entry Angle | Top | |
| Standards/Approvals | UL 50, IEC 60529, DNV GL, CSA-C22.2 No. 182.3 ECBT8.E235076, UL 1977 ECBT2.E235076, UL 50E | |
| Thread Size | PG42 | |
| Number of Levers | 2 | |
| Select all | ||
|---|---|---|
Brand HARTING | ||
Product Type Heavy Duty Power Connector Hood | ||
Locking Type Double Lever | ||
Series 930 | ||
Sub Type Connector Hood | ||
Manufacturer Size Code 32B | ||
Body Material Die Cast Aluminium | ||
IP Rating IP65 | ||
Cable Entry Angle Top | ||
Standards/Approvals UL 50, IEC 60529, DNV GL, CSA-C22.2 No. 182.3 ECBT8.E235076, UL 1977 ECBT2.E235076, UL 50E | ||
Thread Size PG42 | ||
Number of Levers 2 | ||
Hoods and Housing 32B
Two locking levers on housings
Cable gland available separately, see stock no. 313-6477 (typical of range)
Range 9 - (Harting Size 32B)
These hoods and housings are compatible with appropriate inserts from the Han D®, DD, E, EE, HsB, Com and Modular series. The 'compatibility' table associated with item type 1 details that relationship by indicating the specific Harting insert series, together with a stock number typical of each insert range.
Note
These size 32B housings will accommodate two size 16B inserts. They will also accommodate two 4-module frames selected from the Han Modular Series.
Warning
These connectors should not be mated or unmated under electrical load. Connectors of the same or different types arranged in a line should be polarised to prevent the possibility of wrong connection.
Approvals
UL, CSA, SEV
