    Bopla Bocube Series Grey Polycarbonate Enclosure, IP66, IP68, Flanged, Transparent Lid, 271 x 170 x 90mm

    RS Stock No.:
    773-9676
    Mfr. Part No.:
    96026334
    Brand:
    Bopla
    Bopla
    View all General Purpose Enclosures
    7 In stock - FREE next working day delivery available
    2 available from Europe for delivery within 1 working day(s).
    Add to Basket
    Units

    Added

    Price Each

    £54.74

    (exc. VAT)

    £65.69

    (inc. VAT)

    UnitsPer unit
    1 - 9£54.74
    10 - 14£52.49
    15 +£50.26
    RS Stock No.:
    773-9676
    Mfr. Part No.:
    96026334
    Brand:
    Bopla
    COO (Country of Origin):
    HU

    Legislation and Compliance

    COO (Country of Origin):
    HU

    Product Details

    Bopla Bocube Polycarbonate Enclosures


    Introducing the Bocube polycarbonate enclosures from Bopla. A unique and innovative general purpose enclosure that is ideal for wall mount or desktop applications for industrial or office environments. Available in either light grey (RAL7035) or graphite grey (RAL7024), these versatile polycarbonates enclosures are available in various sizes and features a captive transparent, light grey or graphite grey lid with a 0.5 mm or 2 mm deep recessed membrane keypad area.

    Why would you buy the product?


    Bocube enclosures offer the ultimate in protection for electronics and switchgear with an added layer of security. They are designed with very few parts which can quickly and easily be assembled with no need for special tools. The patented hinge is a game changer, it offers quick-release catch technology without screws which can be opened with a screwdriver and closed by hand.

    Features & Benefits


    • Polycarbonate (PC) UL 94 V0 (flame resistant and self-extinguishing) with foamed in seal
    • PCBs and front panels can be mounted in the lid and base
    • Recessed membrane keypad area
    • Large mounting area for connectors, cable glands and operating elements
    • Available in light grey (RAL7035) or graphite grey (RAL7024)
    • Hinged quick release latch (enclosure can also be screwed shut)
    • A lead seal can be fitted to protect against unauthorised entry (not supplied)
    • Recyclable
    • IP Rating: IP66 / IP68
    • RoHS compliant

    Typical Applications


    • Cable/Wire Management
    • IT/Server
    • Solar Power Batteries
    • Oil and Gas Production
    • Food and Beverage Industry
    • Telecommunication Industry

    Compatible Accessories


    Bopla Wall Brackets for use with Bocube Enclosure: Light Grey = RS Stock no: 773-9682, Graphite Grey = RS Stock no: 773-9673
    • 11 mm Pressure Compensation Element for use with Bocube Enclosure - RS Stock no: 907-5315

    (IP) Ingress Protection and what it means


    IP rating classifies the degrees of protection provided against the intrusion of solid objects (including body parts like hands and fingers), dust, accidental contact and water in electrical enclosures.

    Frequently Asked Questions


    Can the enclosure be used outside?

    Bocube enclosures with an IP66/68 rating is dustproof and fully protected when submerged in water – 1.2 m (2 hrs)

    Does this product have RFI shielding?

    No, this product does not have RFI shielding

    What is supplied?

    Lid and base, hinged quick-release catches

    Note


    • Wall brackets are available separately and are drilled to screw holes in the base of the enclosure (except RS stock no: 907-5466, 907-5460, 907-5479, 907-5472).

    Membrane Recess Keypad Area


    RS stock no: 773-9461, 773-9465, 773-9474 and 773-9477 feature a 0.5 mm recess.

    Standards

    IP 66/68 1.2m (2 Hours) DIN 60529.

    Specifications

    AttributeValue
    Body MaterialPolycarbonate
    External Length271 mm
    External Height90 mm
    External Width170 mm
    External Dimensions271 x 170 x 90mm
    IP RatingIP66, IP68
    ColourGrey
    Lid ColourTransparent
    FlangedYes
    ShieldedNo
    SeriesBocube
    Weight651g
    Gasket MaterialFoamed Polyurethane
