Hammond 1591 Series Grey Flame Retardant ABS Enclosure, IP54, Grey Lid, 121 x 94 x 34mm
- RS Stock No.:
- 493-6183
- Mfr. Part No.:
- 1591GGY
- Brand:
- Hammond
Subtotal (1 unit)*
£7.81
(exc. VAT)
£9.37
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 5 unit(s) ready to ship
- Plus 20 unit(s) ready to ship from another location
- Plus 12 unit(s) shipping from 28 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £7.81 |
*price indicative
- RS Stock No.:
- 493-6183
- Mfr. Part No.:
- 1591GGY
- Brand:
- Hammond
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hammond | |
| Body Material | Flame Retardant ABS | |
| External Length | 121 mm | |
| External Height | 34 mm | |
| External Width | 94 mm | |
| External Dimensions | 121 x 94 x 34mm | |
| IP Rating | IP54 | |
| Range | 1591 | |
| Colour | Grey | |
| Lid Colour | Grey | |
| Flanged | No | |
| Shielded | No | |
| Series | 1591 | |
| Number Of Knockouts | 0 | |
| Weight | 95g | |
| Explosion Proof | No | |
Select all | ||
|---|---|---|
Brand Hammond | ||
Body Material Flame Retardant ABS | ||
External Length 121 mm | ||
External Height 34 mm | ||
External Width 94 mm | ||
External Dimensions 121 x 94 x 34mm | ||
IP Rating IP54 | ||
Range 1591 | ||
Colour Grey | ||
Lid Colour Grey | ||
Flanged No | ||
Shielded No | ||
Series 1591 | ||
Number Of Knockouts 0 | ||
Weight 95g | ||
Explosion Proof No | ||
- COO (Country of Origin):
- CA
Hammond 1591 Multi-purpose Plastic Enclosures
The Hammond 1591 series is a multi-purpose plastic enclosure ideally suited for mounting printed circuit boards (PCBs) horizontally. The internal sides of the enclosure are smooth for easy connector installation. Each enclosure has 2 PC board standoffs moulded into the interior and a lap joint construction which provides IP54 protection against the access of dust and splashing water. The Hammond 1591 series is perfect for applications where repetitive assembly and disassembly are required.
Features and Benefits:
• Two piece lap joint construction
• Provides protection against dust accumulation and splashing water
• Integral card guides accept 1.5mm PC cards
• Lid secured with M3 x 10 mm machine screws, threaded into plastic tapped holes
• Provides protection against dust accumulation and splashing water
• Integral card guides accept 1.5mm PC cards
• Lid secured with M3 x 10 mm machine screws, threaded into plastic tapped holes
FAQ:
What does IP mean?
The IP rating is used to define levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies (tools, dirt etc) and moisture. For more information please, visit SELECTION section at the top of the page or click on Selection Guide of an Enclosures.
What is supplied?
What is Supplied?
This enclosure comes complete with 4 x M3x10mm Phillips screws
Note
• Dimensions do not include the lid and exclude flanges (add 4mm to height for the lid)
• Black enclosures include black screws, grey enclosures are standard nickel finish screws.
• Black enclosures include black screws, grey enclosures are standard nickel finish screws.
Approvals
Material Flamability Rating: UL94-V0
