Schneider Electric PanelSeT SM Series Enclosure: Light Grey, Handle: Black Grey Lid Sheet Steel General Purpose
- RS Stock No.:
- 236-3014
- Mfr. Part No.:
- NSYSM1612302DP
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£1,132.31
(exc. VAT)
£1,358.77
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 28 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,132.31 |
*price indicative
Our Better World range features products that make it easy for you to make a greener product choice you can trust.
Learn more about RS Better World products
- RS Stock No.:
- 236-3014
- Mfr. Part No.:
- NSYSM1612302DP
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Product Type | General Purpose Enclosure | |
| Body Material | Sheet Steel | |
| External Height | 1600mm | |
| External Width | 1200mm | |
| IP Rating | IP55 | |
| Colour | Enclosure: Light Grey, Handle: Black | |
| Lid Colour | Grey | |
| Hazardous Area Certification | No | |
| Series | PanelSeT SM | |
| Mounting plate | Yes | |
| Weight | 130.5kg | |
| Standards/Approvals | IEC 62208, UL BV DNV | |
| Transparent Door | No | |
| Better World Product | Yes | |
| Better World Claim | Designed for Disassembly | |
| IK Rating | IK10 | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Product Type General Purpose Enclosure | ||
Body Material Sheet Steel | ||
External Height 1600mm | ||
External Width 1200mm | ||
IP Rating IP55 | ||
Colour Enclosure: Light Grey, Handle: Black | ||
Lid Colour Grey | ||
Hazardous Area Certification No | ||
Series PanelSeT SM | ||
Mounting plate Yes | ||
Weight 130.5kg | ||
Standards/Approvals IEC 62208, UL BV DNV | ||
Transparent Door No | ||
Better World Product Yes | ||
Better World Claim Designed for Disassembly | ||
IK Rating IK10 | ||
- COO (Country of Origin):
- ES
The Schneider Electric spacial series compact enclosure with mounting plate which is used for multiple application. It has dimension of 1600 X 1200 X 300 mm and has 2 doors. It is grey in colour and has surface finish of epoxy polyester powder.
IP degree of protection IP55 conforming to IEC 60529
Certifications UL, BV, DNV
Standards IEC 62208
Green premium product
Enclosure mounting floor-standing
