Hammond 1590Z Series Black, Grey, Natural Die Cast Aluminium Alloy Enclosure, IP68, IK08 60 mm, 361 mm, 120 mm
- RS Stock No.:
- 229-1620
- Mfr. Part No.:
- 1590Z164BK
- Brand:
- Hammond
Subtotal (1 unit)*
£100.50
(exc. VAT)
£120.60
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 08 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £100.50 |
*price indicative
- RS Stock No.:
- 229-1620
- Mfr. Part No.:
- 1590Z164BK
- Brand:
- Hammond
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hammond | |
| Product Type | Enclosure | |
| Body Material | Die Cast Aluminium Alloy | |
| External Height | 60mm | |
| External Width | 120mm | |
| External Length | 361mm | |
| IP Rating | IP68 | |
| Lid Colour | Black | |
| Colour | Black, Grey, Natural | |
| Flanged | No | |
| Hazardous Area Certification | NO | |
| Series | 1590Z | |
| Standards/Approvals | RoHS | |
| IK Rating | IK08 | |
| Gasket Material | Silicone Rubber | |
| Explosion Proof | No | |
| Select all | ||
|---|---|---|
Brand Hammond | ||
Product Type Enclosure | ||
Body Material Die Cast Aluminium Alloy | ||
External Height 60mm | ||
External Width 120mm | ||
External Length 361mm | ||
IP Rating IP68 | ||
Lid Colour Black | ||
Colour Black, Grey, Natural | ||
Flanged No | ||
Hazardous Area Certification NO | ||
Series 1590Z | ||
Standards/Approvals RoHS | ||
IK Rating IK08 | ||
Gasket Material Silicone Rubber | ||
Explosion Proof No | ||
The Hammond type 4X/ 6P die cast aluminium enclosure is watertight, UL listed and has thick walls. It is two piece tongue & groove construction with a replaceable one-piece silicone rubber gasket provides protection against access of dust and water. Gasket supplied loose inside the enclosure (not pre-installed). Four recessed stainless steel machine screws secure lid into tapped holes. It is easy to wall mount using through box - blind hole construction, outside of gasket protection. it is black in colour and has 361 x 120 x 60 mm dimensions.
It has IP68 protection
Its gasket has a temperature rating of -40°C to +150°C
Ideal for repetitive opening and closing
