Microchip MIC4429YN, Dual 2, 6 A 8-Pin 18 V, SOIC
- RS Stock No.:
- 649-424
- Mfr. Part No.:
- MIC4429YN
- Brand:
- Microchip
Bulk discount available
View bulk pricing optionsSubtotal (1 pack of 5 units)*
£7.27
(exc. VAT)
£8.725
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 115 unit(s) shipping from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 45 | £1.454 | £7.27 |
| 50 - 245 | £1.28 | £6.40 |
| 250 - 495 | £1.148 | £5.74 |
| 500 + | £0.916 | £4.58 |
*price indicative
- RS Stock No.:
- 649-424
- Mfr. Part No.:
- MIC4429YN
- Brand:
- Microchip
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Microchip | |
| Product Type | Gate Driver | |
| Output Current | 6A | |
| Pin Count | 8 | |
| Package Type | SOIC | |
| Fall Time | 13ns | |
| Number of Outputs | 1 | |
| Driver Type | Dual | |
| Rise Time | 60ns | |
| Minimum Supply Voltage | 18V | |
| Maximum Supply Voltage | 18V | |
| Number of Drivers | 2 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Series | MIC4420/9 | |
| Standards/Approvals | RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Microchip | ||
Product Type Gate Driver | ||
Output Current 6A | ||
Pin Count 8 | ||
Package Type SOIC | ||
Fall Time 13ns | ||
Number of Outputs 1 | ||
Driver Type Dual | ||
Rise Time 60ns | ||
Minimum Supply Voltage 18V | ||
Maximum Supply Voltage 18V | ||
Number of Drivers 2 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Series MIC4420/9 | ||
Standards/Approvals RoHS | ||
Automotive Standard No | ||
- COO (Country of Origin):
- TH
The Microchip Gate drivers are tough, efficient, and easy to use. They accepts any logic input from 2.4 V to VS without external speed-up capacitors or resistor networks. Proprietary circuits allow the input to swing negative by as much as 5 V without damaging the part. Additional circuits protect against damage from electrostatic discharge.
Logic input withstands negative swing of up to 5 V
Matched rise and fall times of 25 ns
High peak output current at 6 A
