EPCOS B32560 Polyester Film Capacitor, 400V dc, ±10%, 2.2nF, Through Hole
- RS Stock No.:
- 896-1436P
- Mfr. Part No.:
- B32560J6222K000
- Brand:
- EPCOS
Bulk discount available
Subtotal 250 units (supplied in a bag)*
£24.25
(exc. VAT)
£29.00
(inc. VAT)
FREE delivery for orders over £50.00
Being discontinued
- Final 250 unit(s), ready to ship
Units | Per unit |
|---|---|
| 250 - 950 | £0.097 |
| 1000 - 2450 | £0.086 |
| 2500 + | £0.074 |
*price indicative
- RS Stock No.:
- 896-1436P
- Mfr. Part No.:
- B32560J6222K000
- Brand:
- EPCOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EPCOS | |
| Capacitance | 2.2nF | |
| Voltage | 400V dc | |
| Mounting Type | Through Hole | |
| Tolerance | ±10% | |
| Series | B32560 | |
| Lead Pitch | 7.5mm | |
| Length | 9mm | |
| Depth | 2.5mm | |
| Height | 5.5mm | |
| Dimensions | 9 x 2.5 x 5.5mm | |
| Dielectric | Polyester | |
| Terminal Type | Radial | |
| Dissipation Factor | 30 % @ 100 kHz | |
| Maximum Operating Temperature | +125°C | |
| Lead Diameter | 0.5mm | |
| Minimum Operating Temperature | -55°C | |
Select all | ||
|---|---|---|
Brand EPCOS | ||
Capacitance 2.2nF | ||
Voltage 400V dc | ||
Mounting Type Through Hole | ||
Tolerance ±10% | ||
Series B32560 | ||
Lead Pitch 7.5mm | ||
Length 9mm | ||
Depth 2.5mm | ||
Height 5.5mm | ||
Dimensions 9 x 2.5 x 5.5mm | ||
Dielectric Polyester | ||
Terminal Type Radial | ||
Dissipation Factor 30 % @ 100 kHz | ||
Maximum Operating Temperature +125°C | ||
Lead Diameter 0.5mm | ||
Minimum Operating Temperature -55°C | ||
B32560 / B32562 Series
Stacked-film radial wire-ended metallised polyester film capacitors
These devices are uncoated so care must be taken to observe creepage and clearances to adjacent live parts
Ideal for general consumer and industrial electronics applications including lamp ballast circuits for energy saving lamps
These devices are uncoated so care must be taken to observe creepage and clearances to adjacent live parts
Ideal for general consumer and industrial electronics applications including lamp ballast circuits for energy saving lamps
