KEMET C27 Metallised Polypropylene Film Capacitor, 470V ac, ±5%, 2μF, Chassis Mount
- RS Stock No.:
- 377-9018
- Mfr. Part No.:
- C274ACF4200SA0J
- Brand:
- KEMET
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£7.22
(exc. VAT)
£8.66
(inc. VAT)
- RS Stock No.:
- 377-9018
- Mfr. Part No.:
- C274ACF4200SA0J
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Capacitance | 2µF | |
| Voltage | 470V ac | |
| Mounting Type | Chassis Mount | |
| Tolerance | ±5% | |
| Series | C27 | |
| Height | 57mm | |
| Dimensions | 25 (Dia.) x 57mm | |
| Dielectric | Metallised Polypropylene | |
| Terminal Type | Screw Mount | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -25°C | |
Select all | ||
|---|---|---|
Brand KEMET | ||
Capacitance 2µF | ||
Voltage 470V ac | ||
Mounting Type Chassis Mount | ||
Tolerance ±5% | ||
Series C27 | ||
Height 57mm | ||
Dimensions 25 (Dia.) x 57mm | ||
Dielectric Metallised Polypropylene | ||
Terminal Type Screw Mount | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -25°C | ||
C274 ACF Series
KEMET C27 series are polypropylene metallized film capacitors that are cylindrical, plastic can packaged and filled with resin, These capacitors are ideal for AC motor applications
Features and Benefits
Self healing
High capacitance density
Polypropylene is used as a dielectric
Capacitance value ranges from 1μF to 60μF
Rated for continuous service
High capacitance density
Polypropylene is used as a dielectric
Capacitance value ranges from 1μF to 60μF
Rated for continuous service
Applications
Consumer Electronics
Industrial
Portable Devices
Motor drive and control
Power Management
Industrial
Portable Devices
Motor drive and control
Power Management
Standards
EN 60252-1. Approvals: IMQ 85°, IMQ 100°
Note
Alternative product available (see link)1810228 - Alternative Capacitor function & attributes will remain the same, except Nuts and washers will be packed in separate Plastic Bag in each box. This product will eventually replace this article.
