EPCOS B32524 Polyester Film Capacitor, 160 V ac, 250 V dc, ±10%, 2.2μF, Through Hole
- RS Stock No.:
- 194-3529
- Mfr. Part No.:
- B32524Q3225K000
- Brand:
- EPCOS
Subtotal (1 box of 320 units)*
£251.52
(exc. VAT)
£301.76
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 960 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
---|---|---|
320 + | £0.786 | £251.52 |
*price indicative
- RS Stock No.:
- 194-3529
- Mfr. Part No.:
- B32524Q3225K000
- Brand:
- EPCOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | EPCOS | |
Capacitance | 2.2µF | |
Voltage | 160 V ac, 250 V dc | |
Mounting Type | Through Hole | |
Tolerance | ±10% | |
Series | B32524 | |
Lead Pitch | 27.5mm | |
Automotive Standard | AEC-Q200D | |
Length | 31.5mm | |
Depth | 11mm | |
Height | 21mm | |
Dimensions | 31.5 x 11 x 21mm | |
Dielectric | Polyester | |
Terminal Type | Solder | |
Lead Diameter | 0.8mm | |
Select all | ||
---|---|---|
Brand EPCOS | ||
Capacitance 2.2µF | ||
Voltage 160 V ac, 250 V dc | ||
Mounting Type Through Hole | ||
Tolerance ±10% | ||
Series B32524 | ||
Lead Pitch 27.5mm | ||
Automotive Standard AEC-Q200D | ||
Length 31.5mm | ||
Depth 11mm | ||
Height 21mm | ||
Dimensions 31.5 x 11 x 21mm | ||
Dielectric Polyester | ||
Terminal Type Solder | ||
Lead Diameter 0.8mm | ||
B32521...B32524 Series
Typical applications are general purchase blocking, coupling, decoupling, bypassing, and RFI for automotive
High pulse strength
High contact reliability
Stacked-film and wound technology
Plastic case with epoxy resin sealing (UL 94 V-0)
High pulse strength
High contact reliability
Stacked-film and wound technology
Plastic case with epoxy resin sealing (UL 94 V-0)
