EPCOS B32522 Polyester Film Capacitor, 40 V ac, 63 V dc, ±10%, 6.8μF, Through Hole
- RS Stock No.:
- 185-4968P
- Mfr. Part No.:
- B32522C0685K000
- Brand:
- EPCOS
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 185-4968P
- Mfr. Part No.:
- B32522C0685K000
- Brand:
- EPCOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EPCOS | |
| Capacitance | 6.8µF | |
| Voltage | 40 V ac, 63 V dc | |
| Mounting Type | Through Hole | |
| Tolerance | ±10% | |
| Series | B32522 | |
| Automotive Standard | AEC-Q200D | |
| Lead Pitch | 15mm | |
| Length | 8.5mm | |
| Depth | 14.5mm | |
| Height | 18mm | |
| Dimensions | 8.5 x 14.5 x 18mm | |
| Dielectric | Polyester | |
| Terminal Type | Solder | |
| Lead Diameter | 0.8mm | |
| Dissipation Factor | 10 x 10^-3% | |
| Maximum Operating Temperature | +125°C | |
Select all | ||
|---|---|---|
Brand EPCOS | ||
Capacitance 6.8µF | ||
Voltage 40 V ac, 63 V dc | ||
Mounting Type Through Hole | ||
Tolerance ±10% | ||
Series B32522 | ||
Automotive Standard AEC-Q200D | ||
Lead Pitch 15mm | ||
Length 8.5mm | ||
Depth 14.5mm | ||
Height 18mm | ||
Dimensions 8.5 x 14.5 x 18mm | ||
Dielectric Polyester | ||
Terminal Type Solder | ||
Lead Diameter 0.8mm | ||
Dissipation Factor 10 x 10^-3% | ||
Maximum Operating Temperature +125°C | ||
- COO (Country of Origin):
- BR
High pulse strength
High contact reliability
RoHS-compatible
Halogen-free capacitors available on request
AEC-Q200D compliant
Terminals:Parallel wire leads, lead-free tinned
High contact reliability
RoHS-compatible
Halogen-free capacitors available on request
AEC-Q200D compliant
Terminals:Parallel wire leads, lead-free tinned
