NISSEI AMZ Polyester Capacitor PET, 100V dc, ±5%, 100pF, Through Hole

View all Film Capacitors
Currently unavailable
Sorry, we don't know when this will be back in stock.
RS Stock No.:
183-3088
Mfr. Part No.:
AMZB0100J10100000000
Brand:
NISSEI
Find similar products by selecting one or more attributes.
Select all

Brand

NISSEI

Capacitance

100pF

Voltage

100V dc

Mounting Type

Through Hole

Tolerance

±5%

Series

AMZ

Lead Pitch

3.5mm

Length

5.7mm

Depth

3.7mm

Height

7.5mm

Dimensions

5.7 x 3.7 x 7.5mm

Dissipation Factor

0.008%

Lead Diameter

0.5mm

Maximum Operating Temperature

+85°C

Minimum Operating Temperature

-40°C

COO (Country of Origin):
JP

NISSEI Polyester Capacitor


The NISSEI AMZ series, 100pF is a through-hole mount polyester capacitor. It has a voltage rating of 100VDC.

Features and Benefits


• Auto insertion
• Insulation resistance is 30000mohm
• Lead pitch is 3.5mm
• Operating temperature ranges between -40°C and 85°C
• Small allowance in the lead pitch dimensions
• Small size, in H dimension that is advantageous to save space of PCB
• Tolerance is ±5%

Applications


• general-purpose
• Industrial
• Snubber circuits

Certifications

• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
