NISSEI AMZ Polyester Capacitor PET, 50V dc, ±5%, 3.3nF, Through Hole
- RS Stock No.:
- 183-3336
- Mfr. Part No.:
- AMZ0050J33200000000
- Brand:
- NISSEI
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 183-3336
- Mfr. Part No.:
- AMZ0050J33200000000
- Brand:
- NISSEI
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NISSEI | |
| Capacitance | 3.3nF | |
| Voltage | 50V dc | |
| Mounting Type | Through Hole | |
| Tolerance | ±5% | |
| Series | AMZ | |
| Lead Pitch | 3.5mm | |
| Length | 4.8mm | |
| Depth | 2.8mm | |
| Height | 7mm | |
| Dimensions | 4.8 x 2.8 x 7mm | |
| Dissipation Factor | 0.008% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Lead Diameter | 0.5mm | |
Select all | ||
|---|---|---|
Brand NISSEI | ||
Capacitance 3.3nF | ||
Voltage 50V dc | ||
Mounting Type Through Hole | ||
Tolerance ±5% | ||
Series AMZ | ||
Lead Pitch 3.5mm | ||
Length 4.8mm | ||
Depth 2.8mm | ||
Height 7mm | ||
Dimensions 4.8 x 2.8 x 7mm | ||
Dissipation Factor 0.008% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Lead Diameter 0.5mm | ||
- COO (Country of Origin):
- JP
Very small size, especially in H dimension, which is advantageous to save space of PC Board.
Good reputations for use in general and industrial application.
Small allowance in the lead pitch dimensions.
Suitable for automatic insertion due to their small size and light weight.
General purpose application
Snubber circuits
Good reputations for use in general and industrial application.
Small allowance in the lead pitch dimensions.
Suitable for automatic insertion due to their small size and light weight.
General purpose application
Snubber circuits
