EPCOS B81123 Metallised Polypropylene Film Capacitor, 3 kV dc, 500 V ac, ±20%, 1nF, Through Hole
- RS Stock No.:
- 172-5623
- Mfr. Part No.:
- B81123C1102M000
- Brand:
- EPCOS
Bulk discount available
Subtotal (1 bag of 1000 units)*
£191.00
(exc. VAT)
£229.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 19,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 1000 - 1000 | £0.191 | £191.00 |
| 2000 + | £0.162 | £162.00 |
*price indicative
- RS Stock No.:
- 172-5623
- Mfr. Part No.:
- B81123C1102M000
- Brand:
- EPCOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EPCOS | |
| Capacitance | 1nF | |
| Voltage | 3 kV dc, 500 V ac | |
| Mounting Type | Through Hole | |
| Tolerance | ±20% | |
| Series | B81123 | |
| Lead Pitch | 15mm | |
| Suppression Class | Y1 | |
| Length | 18mm | |
| Depth | 5mm | |
| Lead Length | 6mm | |
| Height | 10.5mm | |
| Dimensions | 18 x 5 x 10.5mm | |
| Dielectric | Metallised Polypropylene | |
| Terminal Type | Radial | |
| Lead Diameter | 0.8mm | |
| Maximum Operating Temperature | +110°C | |
| Dissipation Factor | 1 % @ 1 kHz, 5 % @ 100 kHz | |
Select all | ||
|---|---|---|
Brand EPCOS | ||
Capacitance 1nF | ||
Voltage 3 kV dc, 500 V ac | ||
Mounting Type Through Hole | ||
Tolerance ±20% | ||
Series B81123 | ||
Lead Pitch 15mm | ||
Suppression Class Y1 | ||
Length 18mm | ||
Depth 5mm | ||
Lead Length 6mm | ||
Height 10.5mm | ||
Dimensions 18 x 5 x 10.5mm | ||
Dielectric Metallised Polypropylene | ||
Terminal Type Radial | ||
Lead Diameter 0.8mm | ||
Maximum Operating Temperature +110°C | ||
Dissipation Factor 1 % @ 1 kHz, 5 % @ 100 kHz | ||
B81123 Series
Suitable for double or reinforced insulated applications (class Y1)
250Vac rating for use in Y class line to ground applications
Self extinguishing UL94V-0 encapsulation material
Excellent self-healing properties ensuring long life
250Vac rating for use in Y class line to ground applications
Self extinguishing UL94V-0 encapsulation material
Excellent self-healing properties ensuring long life
Standards
EN 60384-14, IEC 60384-14, UL 1414 (double protection)
Y Class - Y1
