Nichicon YX Polyester Film Capacitor, 100V dc, ±10%, 100nF, Radial

View all Film Capacitors
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
RS Stock No.:
167-1141
Mfr. Part No.:
QYX2A104KTP
Brand:
Nichicon
Find similar products by selecting one or more attributes.
Select all

Brand

Nichicon

Capacitance

100nF

Voltage

100V dc

Mounting Type

Radial

Tolerance

±10%

Series

YX

Lead Pitch

7.5mm

Length

11mm

Depth

5.5mm

Height

14mm

Dimensions

11 x 5.5 x 14mm

Dielectric

Polyester

Terminal Type

Radial

Minimum Operating Temperature

-40°C

Lead Diameter

0.5mm

Maximum Operating Temperature

+85°C

Package/Case

5101-1

COO (Country of Origin):
JP

YX Series Plastic Film Capacitors


These Nichicon brand YX series capacitors feature a polyester film and aluminium foil dielectric and are well suited to commercial and industrial applications. They are coated with an epoxy resin that is flame-retardant and resistant against humidity and solvents.
