Murata Ferrite Bead 0.85 mm (Solder) (0805) (Chip Ferrite Bead), 330 Ω impedance at 100 MHz
- RS Stock No.:
- 839-0821
- Mfr. Part No.:
- BLM21PG331SH1D
- Brand:
- Murata
Bulk discount available
Subtotal (1 bag of 50 units)*
£3.65
(exc. VAT)
£4.40
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2,300 unit(s) shipping from 27 April 2026
- Plus 3,900 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 50 - 450 | £0.073 | £3.65 |
| 500 - 950 | £0.062 | £3.10 |
| 1000 - 2450 | £0.055 | £2.75 |
| 2500 - 4950 | £0.047 | £2.35 |
| 5000 + | £0.044 | £2.20 |
*price indicative
- RS Stock No.:
- 839-0821
- Mfr. Part No.:
- BLM21PG331SH1D
- Brand:
- Murata
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Murata | |
| Package Type | 0805 | |
| Product Type | Ferrite Bead | |
| Impedance at 100 MHz | 330Ω | |
| Current Rating | 1.5A | |
| Sub Type | Chip Ferrite Bead | |
| Mount Type | Solder | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 125°C | |
| Length | 2mm | |
| Standards/Approvals | RoHS | |
| Maximum DC Resistance | 70mΩ | |
| Height | 0.85mm | |
| Depth | 1.25mm | |
| Application | EMI Suppression Filter, Power Supplies | |
| Automotive Standard | AEC-Q200 | |
| Series | BLM21PG | |
| Material | Ferrite | |
| Select all | ||
|---|---|---|
Brand Murata | ||
Package Type 0805 | ||
Product Type Ferrite Bead | ||
Impedance at 100 MHz 330Ω | ||
Current Rating 1.5A | ||
Sub Type Chip Ferrite Bead | ||
Mount Type Solder | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
Length 2mm | ||
Standards/Approvals RoHS | ||
Maximum DC Resistance 70mΩ | ||
Height 0.85mm | ||
Depth 1.25mm | ||
Application EMI Suppression Filter, Power Supplies | ||
Automotive Standard AEC-Q200 | ||
Series BLM21PG | ||
Material Ferrite | ||
- COO (Country of Origin):
- JP
SMD 0805 Ferrite Filters- BLM21P Series
BLM series ferrite beads from Murata do not require a ground connection and are Ideal for use in circuits with unstable ground lines. At noise frequencies, these ferrite beads are designed to function nearly as resistors, leaving signal wave forms undistorted and reducing the possibility of resonance. The nickel barrier construction of the external electrodes enables excellent solder heat resistance. Filters composed of ferrite pearl inductance are designed to remove EMI from continuous voltage lines.
BLM_P ferrite beads have low DC resistance, making them Ideal for high current circuits.
This series of ferrite beads are designed for general use applications.
