Bourns Ferrite Bead 1.1 mm (Surface) (1206) (EMI Filter & Protection), 55 Ω impedance at 25 MHz, 120 Ω impedance at 100
- RS Stock No.:
- 262-9177
- Mfr. Part No.:
- MU3261-121Y
- Brand:
- Bourns
Bulk discount available
View bulk pricing optionsSubtotal (1 tape of 10 units)*
£1.40
(exc. VAT)
£1.70
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2,650 unit(s) shipping from 17 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 90 | £0.14 | £1.40 |
| 100 - 240 | £0.126 | £1.26 |
| 250 - 490 | £0.099 | £0.99 |
| 500 - 990 | £0.077 | £0.77 |
| 1000 + | £0.063 | £0.63 |
*price indicative
- RS Stock No.:
- 262-9177
- Mfr. Part No.:
- MU3261-121Y
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Package Type | 1206 | |
| Product Type | Ferrite Bead | |
| Impedance at 25 MHz | 55Ω | |
| Impedance at 50 MHz | 75Ω | |
| Impedance at 100 MHz | 120Ω | |
| Impedance at 300 MHz | 160Ω | |
| Current Rating | 900mA | |
| Sub Type | EMI Filter & Protection | |
| Mount Type | Surface | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | RoHS | |
| Length | 3.2mm | |
| Maximum DC Resistance | 0.15Ω | |
| Height | 1.1mm | |
| Material | Ferrite | |
| Series | MU | |
| Application | Ic Power Line, Power Supplies, Signal Line | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Package Type 1206 | ||
Product Type Ferrite Bead | ||
Impedance at 25 MHz 55Ω | ||
Impedance at 50 MHz 75Ω | ||
Impedance at 100 MHz 120Ω | ||
Impedance at 300 MHz 160Ω | ||
Current Rating 900mA | ||
Sub Type EMI Filter & Protection | ||
Mount Type Surface | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals RoHS | ||
Length 3.2mm | ||
Maximum DC Resistance 0.15Ω | ||
Height 1.1mm | ||
Material Ferrite | ||
Series MU | ||
Application Ic Power Line, Power Supplies, Signal Line | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Bourns high impedance chip ferrite beads has high resistance to heat and humidity. It is used in power supply lines, IC power lines and signal lines.
Resistance to mechanical shock and pressure
Accurate dimensions for automatic surface mounting
RoHS compliant
