Belden 1885ENH, 1000 m Cat7 Cable, Orange Low Smoke Zero Halogen Sheath
- RS Stock No.:
- 644-586
- Mfr. Part No.:
- 1885ENH.051000
- Brand:
- Belden
Subtotal (1 reel of 1000 metres)*
£2,330.83
(exc. VAT)
£2,797.00
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 06 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £2,330.83 | £2.331 |
*price indicative
- RS Stock No.:
- 644-586
- Mfr. Part No.:
- 1885ENH.051000
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Belden | |
| Product Type | Cat7 Cable | |
| Series | 1885ENH | |
| Cable Length | 1000m | |
| Sub Type | Cat7 Cable | |
| Jacket Material | Low Smoke Zero Halogen | |
| Jacket Colour | Orange | |
| Conductor Type | Solid | |
| Minimum Operating Temperature | 30°C | |
| Maximum Operating Temperature | 60°C | |
| Fire Behaviour | IEC 60332-1-2 | |
| Standards/Approvals | REACH, IEC 60332-1-2, RoHS, EU CE | |
| Outside Diameter | 7mm | |
| Number of Cores | 4 | |
| Voltage | 72V | |
| Conductor Material | Bare Copper | |
| Select all | ||
|---|---|---|
Brand Belden | ||
Product Type Cat7 Cable | ||
Series 1885ENH | ||
Cable Length 1000m | ||
Sub Type Cat7 Cable | ||
Jacket Material Low Smoke Zero Halogen | ||
Jacket Colour Orange | ||
Conductor Type Solid | ||
Minimum Operating Temperature 30°C | ||
Maximum Operating Temperature 60°C | ||
Fire Behaviour IEC 60332-1-2 | ||
Standards/Approvals REACH, IEC 60332-1-2, RoHS, EU CE | ||
Outside Diameter 7mm | ||
Number of Cores 4 | ||
Voltage 72V | ||
Conductor Material Bare Copper | ||
- COO (Country of Origin):
- HU
Belden 1885ENH Series Thin Ethernet Cable, 1000m Cable Length, Orange Jacket - 1885ENH.051000
This thin Ethernet cable provides a compact, low-profile solution for high-speed network links in industrial and commercial installations. Designed for environments where space and safety are priorities, it combines a slim construction with materials suited to constrained routing and mixed indoor/outdoor usage.
Features and Benefits:
• Four solid conductors delivering consistent signal integrity under load
• Low smoke zero halogen jacket reduces toxic emissions in fires
• Meets IEC 60332-1-2 fire behaviour for flame resistance
• Rated to operate up to 60°C for elevated-temperature applications
• 72V voltage tolerance supports a range of powered systems
• Narrow 7mm outside diameter enables tight cable management
• Low smoke zero halogen jacket reduces toxic emissions in fires
• Meets IEC 60332-1-2 fire behaviour for flame resistance
• Rated to operate up to 60°C for elevated-temperature applications
• 72V voltage tolerance supports a range of powered systems
• Narrow 7mm outside diameter enables tight cable management
Applications
• Suitable for factory automation network backbones in plant rooms
• Ideal for electrical control panels requiring Compact cabling
• Used with field devices where low-smoke routing is required
• Can be used for long-run bulk installations from distribution points
• Used for signal transmission in mechanical equipment enclosures
• Ideal for electrical control panels requiring Compact cabling
• Used with field devices where low-smoke routing is required
• Can be used for long-run bulk installations from distribution points
• Used for signal transmission in mechanical equipment enclosures
How many conductors does it contain and what is their form?
It contains four solid-core conductors MADE from bare copper to provide stable, low-resistance connections suitable for fixed installations.
What approvals ensure material and chemical compliance?
It complies with REACH and RoHS, confirming restrictions on hazardous substances for regulated environments.
Is the cable intended for external exposure?
The construction allows use both indoors and outdoors, with a jacket formulated to reduce harmful smoke and corrosion risk, while practical weatherproofing should be assessed per installation.
What Visual identification does the jacket provide?
The sheath is Orange to assist Rapid identification and segregation in multi-cable runs.
