Belden Unterminated, 305 m Cat5E Cable, Green Low Smoke Zero Halogen Sheath

View all Ethernet Cable

Subtotal (1 reel of 305 metres)*

£264.86

(exc. VAT)

£317.83

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later
Reel(s)
Per Reel
Per Metre*
1 +£264.86£0.868

*price indicative

RS Stock No.:
631-572
Mfr. Part No.:
1583ENH.02U305
Brand:
Belden
Find similar products by selecting one or more attributes.
Select all

Brand

Belden

Series

Unterminated

Product Type

Cat5E Cable

Cable Length

305m

Sub Type

Cat5e

Jacket Colour

Green

Jacket Material

Low Smoke Zero Halogen

Minimum Operating Temperature

-30°C

Conductor Type

Stranded

Maximum Operating Temperature

60°C

Standards/Approvals

RoHS, EU CE, REACH, IEC 60332-1-2

Fire Behaviour

IEC 60332-1-2

Outside Diameter

4.6mm

Number of Cores

4

Conductor Material

Bare Copper

Voltage

72V

COO (Country of Origin):
HU

Belden 1583ENH Series Thin Ethernet Cable, 305m Cable Length, Green Jacket - 1583ENH.02U305


This thin Ethernet cable provides slim, low-profile network connectivity for structured wiring in confined or high-density installations. It is intended for data networking where a reduced-diameter Cat5e conductor is required and for environments that demand limited smoke and halogen emissions during combustion.

Features & Benefits


• Stranded bare copper conductors deliver flexible cable routing
• Four-core construction supports standard Cat5e signalling
• Low smoke zero halogen jacket reduces toxic emissions in fires
• Meets IEC60332-1-2 flame test for single-flame resistance
• Rated for operation from -30°C to 60°C for varied environments
• 72V voltage rating supports low-voltage network equipment

**Applications**


• Suitable for high-density patch panels in datacentres
• Ideal for wiring control cabinets in automation systems
• Used with industrial network switches in electronics enclosures
• Can be used for horisontal cabling in office structured cabling
• Used for interconnects where LSZH material is required

What conductor material is used and how does it affect flexibility?


The cable uses stranded bare copper conductors, which increase pliability for frequent bending and tight routing compared with solid cores.

How thin is the cable and where does that help installation?


The cable has a 4.6mm outside diameter, allowing denser cable bundles and easier management in confined trays and ducts.

Which regulatory and material standards relate to the product?


The construction complies with RoHS, EU CE and REACH requirements and the jacket meets IEC60332-1-2 fire behaviour testing.

What colour and jacket material should installers expect for labelling and safety?


The outer sheath is green and manufactured from a low smoke zero halogen compound suitable for areas prioritising reduced toxic emissions.
