Siemens Emergency Stop Push Button, Surface Mount, 2NC, IP65
- RS Stock No.:
- 742-9338
- Mfr. Part No.:
- 3SB3801-0EF3
- Brand:
- Siemens
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£68.30
(exc. VAT)
£81.96
(inc. VAT)
- RS Stock No.:
- 742-9338
- Mfr. Part No.:
- 3SB3801-0EF3
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Mounting Type | Surface Mount | |
| Contact Configuration | 2NC | |
| Illuminated | No | |
| IP Rating | IP65 | |
| Depth | 106mm | |
| Width | 85mm | |
| Push Button Material | Plastic | |
| Bezel Material | Plastic | |
| Height | 85mm | |
Select all | ||
|---|---|---|
Brand Siemens | ||
Mounting Type Surface Mount | ||
Contact Configuration 2NC | ||
Illuminated No | ||
IP Rating IP65 | ||
Depth 106mm | ||
Width 85mm | ||
Push Button Material Plastic | ||
Bezel Material Plastic | ||
Height 85mm | ||
- COO (Country of Origin):
- DE
Control Station with Emergency Stop Button - Plastic
The 3SB3 range of enclosures come with standard fittings. These emergency stop control stations are yellow metal and are equipped with actuators and indicators made of metal.
Plastic enclosure with an ingress protection of IP65
Vertical mounting type
Contact blocks for floor mounting (are snapped into the enclosure base)
Cable entry on the top and bottom 1 x M20 each
Mounting diameter 22mm
Vertical mounting type
Contact blocks for floor mounting (are snapped into the enclosure base)
Cable entry on the top and bottom 1 x M20 each
Mounting diameter 22mm
Siemens Emergency Stop Pushbutton
The Siemens 3SB3 series emergency stop pushbutton has a red mushroom style head with the diameter of 32mm. The housing and the pushbutton are made of plastic material. It is made from yellow metal and is equipped with actuators and indicators made of metal. This pushbutton has a contact current rating of 6A and a voltage rating of 230V.
Phase-out notification:
This product is in obsolescence mode and is due for discontinuation by the manufacturer. We recommend that you review the new pushbutton range SIRIUS ACT, which is an alternative range proposed by the manufacturer. Please refer to the 3SB3/SIRIUS ACT cross-reference guide located in the technical reference section.
Phase-out notification:
This product is in obsolescence mode and is due for discontinuation by the manufacturer. We recommend that you review the new pushbutton range SIRIUS ACT, which is an alternative range proposed by the manufacturer. Please refer to the 3SB3/SIRIUS ACT cross-reference guide located in the technical reference section.
Features and Benefits
• 2NC contact configuration
• Twist to release method
•
Surface mount
• Non-illuminated
• Contact blocks for floor mounting (are snapped into the enclosure base)
• Cable entry on the top and bottom 1 x M20 each
• Mounting diameter is 22mm
• Comes with protective collar
• Twist to release method
•
Surface mount
• Non-illuminated
• Contact blocks for floor mounting (are snapped into the enclosure base)
• Cable entry on the top and bottom 1 x M20 each
• Mounting diameter is 22mm
• Comes with protective collar
Certifications
•
IP65 rated
• UL approved
• EAC certified
• CE certified
• ABS certified
IP65 rated
• UL approved
• EAC certified
• CE certified
• ABS certified
Siemens
