Phoenix Contact RIF Series Interface Relay, DIN Rail, 230V ac Coil, 3PDT, 13mA
- RS Stock No.:
- 794-3658
- Mfr. Part No.:
- 2903292
- Brand:
- Phoenix Contact
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 794-3658
- Mfr. Part No.:
- 2903292
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Coil Resistance | 7.08kΩ | |
| Product Type | Interface Relay | |
| Coil Voltage | 230V ac | |
| Contact Configuration | 3PDT | |
| Mount Type | DIN Rail | |
| Series | RIF | |
| Terminal Type | Plug-In | |
| Switching Current | 2A | |
| Minimum Operating Temperature | -40°C | |
| Switching AC Voltage | 250V ac | |
| Switching DC Voltage | 250V dc | |
| Coil Current | 13mA | |
| Maximum Operating Temperature | 50°C | |
| Contact Material | Silver Alloy | |
| Length | 40mm | |
| Height | 103mm | |
| Standards/Approvals | EAC | |
| Width | 90mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Coil Resistance 7.08kΩ | ||
Product Type Interface Relay | ||
Coil Voltage 230V ac | ||
Contact Configuration 3PDT | ||
Mount Type DIN Rail | ||
Series RIF | ||
Terminal Type Plug-In | ||
Switching Current 2A | ||
Minimum Operating Temperature -40°C | ||
Switching AC Voltage 250V ac | ||
Switching DC Voltage 250V dc | ||
Coil Current 13mA | ||
Maximum Operating Temperature 50°C | ||
Contact Material Silver Alloy | ||
Length 40mm | ||
Height 103mm | ||
Standards/Approvals EAC | ||
Width 90mm | ||
Phoenix Contact Interface Relay, 7.08kΩ Coil Resistance, 2A Switching Current - RIF-3-RPT-LV-230AC/3X21 - 2903292
Bridge the gap between devices with this 3-pole interface relay from Phoenix Contact. It links components with different electric potentials by transmitting digital signals between them to achieve consistent performance. Galvanic isolation guards against interference, so you get reliable communication between controls and instruments.
As the module comes pre-assembled, it's ready to go straight away. Simply clip it onto a DIN rail and plug it in to get on with business. Wiring up is a cinch, thanks to the push-in terminals. For versatility, this unit handles wire sizes between 26 and 16AWG. Highly-conductive silver nickel contacts deliver clear signals and boost efficiency.
For at-a-glance troubleshooting, an LED status indicator lets you know when something's wrong. The integrated varistor protects people and equipment against voltage surges. With a 40 (W) x 103 (H) x 90mm (D) footprint, this device easily squeezes into tight spaces in everything from automated factory processes to medical systems.
Features & Benefits
• Wide operating temperature range between -40°C and +50°C for use in harsh conditions
• DIN EN 50178 approval assures you of the product's safety and reliability
• IEC 62103 compliance indicates the unit has passed quality testing for use in power installations
