ABB R600 Series Interface Relay, DIN Rail, 5V Coil, SPDT, 68mA

Subtotal (1 box of 10 units)*

£209.36

(exc. VAT)

£251.23

(inc. VAT)

Stocked by manufacturer

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Box(es)	Per Box	Per unit*
1 +	£209.36	£20.936

*price indicative

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Coil Voltage	5V
	Product Type	Interface Relay
	Contact Configuration	SPDT
	Mount Type	DIN Rail
	Series	R600
	Terminal Type	Screw
	Switching Current	1A
	Coil Current	68mA
	Switching AC Voltage	240V ac
	Coil Type	Non-Latching
	Switching DC Voltage	60V dc
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	70°C
	Contact Material	Silver Alloy
	Standards/Approvals	RoHS
	Width	10mm
	Height	15mm
	Length	50mm

	Select all
	Brand ABB
	Coil Voltage 5V
	Product Type Interface Relay
	Contact Configuration SPDT
	Mount Type DIN Rail
	Series R600
	Terminal Type Screw
	Switching Current 1A
	Coil Current 68mA
	Switching AC Voltage 240V ac
	Coil Type Non-Latching
	Switching DC Voltage 60V dc
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 70°C
	Contact Material Silver Alloy
	Standards/Approvals RoHS
	Width 10mm
	Height 15mm
	Length 50mm

The ABB interface relay has 1 SPDT output contact rated for 5 to 250VAC. The slim, compact design allow optimization of space within a control panel.

Built in LED

Spring terminals
