ABB CRM Series Interface Relay, DIN Rail, 12V dc Coil, DPDT
- RS Stock No.:
- 231-9489
- Mfr. Part No.:
- 1SVR405611R4000 CR-M012DC2
- Brand:
- ABB
Subtotal (1 unit)*
£7.12
(exc. VAT)
£8.54
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 15 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £7.12 |
*price indicative
- RS Stock No.:
- 231-9489
- Mfr. Part No.:
- 1SVR405611R4000 CR-M012DC2
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Coil Voltage | 12V dc | |
| Product Type | Interface Relay | |
| Contact Configuration | DPDT | |
| Mount Type | DIN Rail | |
| Series | CRM | |
| Terminal Type | Screw | |
| Switching Current | 12A | |
| Switching DC Voltage | 12V dc | |
| Switching AC Voltage | 250V ac | |
| Height | 21.2mm | |
| Standards/Approvals | RoHS | |
| Width | 27.5mm | |
| Length | 35.6mm | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Coil Voltage 12V dc | ||
Product Type Interface Relay | ||
Contact Configuration DPDT | ||
Mount Type DIN Rail | ||
Series CRM | ||
Terminal Type Screw | ||
Switching Current 12A | ||
Switching DC Voltage 12V dc | ||
Switching AC Voltage 250V ac | ||
Height 21.2mm | ||
Standards/Approvals RoHS | ||
Width 27.5mm | ||
Length 35.6mm | ||
- COO (Country of Origin):
- PL
The ABB CR-M series pluggable miniature relays that can be used for electrical isolation, amplification and signal multiplying. As an interface they link the electronic controlling, e.g. PLC, PC or field bus systems and the sensor/actuator level. These interface relays do not use additional internal protective circuits and therefore are overload-proof against short-time variations like current or voltage peaks.
Cadmium-free contact material
LED indication
Higher mechanical and electrical life time
Compact design
