Phoenix Contact RIF-0-RSC-24DC/1AU Series Interface Relay, DIN Rail, 24V dc Coil, SPST, 9mA

RS Stock No.:: 175-0516
Mfr. Part No.:: 2903364
Brand:: Phoenix Contact

Phoenix Contact RIF-0-RSC-24DC/1AU Series Interface Relay, DIN Rail, 24V dc Coil, SPST, 9mA

Currently unavailable

We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.

Alternative

This product is not currently available. Here is our alternative recommendation.

Phoenix Contact RIF-0-RPT-24DC/1AU Series Interface Relay, DIN Rail, 24V dc Coil, SPST, 9mA

RS Stock No.: 794-3759

Each

£8.50

(exc. VAT)

£10.20

(inc. VAT)

RS Stock No.:: 175-0516
Mfr. Part No.:: 2903364
Brand:: Phoenix Contact

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Phoenix Contact
	Coil Voltage	24V dc
	Product Type	Interface Relay
	Contact Configuration	SPST
	Mount Type	DIN Rail
	Series	RIF-0-RSC-24DC/1AU
	Terminal Type	Screw
	Switching Current	50mA
	Coil Current	9mA
	Switching DC Voltage	36V dc
	Switching AC Voltage	30V ac
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	60°C
	Contact Material	Silver Alloy
	Height	84mm
	Standards/Approvals	IEC 60947-5-1
	Width	68mm
	Length	6.2mm

	Select all
	Brand Phoenix Contact
	Coil Voltage 24V dc
	Product Type Interface Relay
	Contact Configuration SPST
	Mount Type DIN Rail
	Series RIF-0-RSC-24DC/1AU
	Terminal Type Screw
	Switching Current 50mA
	Coil Current 9mA
	Switching DC Voltage 36V dc
	Switching AC Voltage 30V ac
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 60°C
	Contact Material Silver Alloy
	Height 84mm
	Standards/Approvals IEC 60947-5-1
	Width 68mm
	Length 6.2mm

COO (Country of Origin):: CZ

Phoenix Contact RIF-0-RSC-24DC/ 1AU Series Interface Relay, 24V DC Coil Voltage, SPST Contact Configuration - 2903364

This interface relay is a pre-assembled relay module designed specifically for automation and control applications. Featuring a coil voltage of 24V DC, it incorporates a single-pole, single-throw (SPST) configuration. Its compact dimensions of 6.2mm width, 68mm depth, and 84mm height make it suitable for installations within confined areas on DIN rails.

Features & Benefits

• High switching voltage of 250V AC/DC allows versatility

• Silver alloy contact ensures superior performance and durability

• Input voltage range from 19.2V to 36V enables flexibility in various systems

• Designed for a mechanical life of 20million cycles increases reliability

• Damping diode for improved coil protection enhances longevity

Applications

• Used in control cabinets for electrical management systems

• Employed in machine automation for reliable actuation processes

• Utilised in commercial building automation systems to optimise functionality

What is the operating temperature range for this relay?

The relay operates effectively within a temperature range of -40°C to +60°C, ensuring performance in various environmental conditions.

How does the relay's switching capacity benefit my application?

The switching capacity of up to 3A at 230V AC and 1A at 24V DC allows the relay to control various loads, providing versatility in automation and control tasks.

What connection methods are available for this device?

It features screw connections for both the coil side and the contact side, allowing secure and straightforward installations with a stripping length of 7mm.
