Hongfa Europe GMBH 2RM Series Interface Relay, DIN Rail Mount, 24V dc Coil, DPDT, 2-Pole, 8A Load
- RS Stock No.:
- 137-2111
- Mfr. Part No.:
- 2RM-24-3
- Brand:
- Hongfa Europe GMBH
Subtotal (1 unit)*
£10.03
(exc. VAT)
£12.04
(inc. VAT)
FREE delivery for orders over £50.00
- Plus 83 unit(s) shipping from 20 October 2025
- Plus 22 unit(s) shipping from 20 October 2025
- Plus 90 unit(s) shipping from 28 October 2025
Units | Per unit |
|---|---|
| 1 + | £10.03 |
*price indicative
- RS Stock No.:
- 137-2111
- Mfr. Part No.:
- 2RM-24-3
- Brand:
- Hongfa Europe GMBH
Select all | Attribute | Value |
|---|---|---|
| Brand | Hongfa Europe GMBH | |
| Coil Voltage | 24V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | DIN Rail | |
| Number of Poles | 2 | |
| Series | 2RM | |
| Load Current Rating | 8A | |
| Maximum Input Voltage | 250V ac | |
| Switching Voltage | 24 V dc → 250V ac | |
| Terminal Type | Screw | |
| Depth | 15.8mm | |
| Height | 52mm | |
| Length | 75mm | |
| Contact Material | Silver Alloy | |
| Input Current | 8A | |
| Maximum Operating Temperature | +85°C | |
| Standards Met | CE, cURus | |
| Operating Temperature Range | -40 → +85°C | |
| Special Features | Change Over Contacts, Supplied Complete, Relay, LED, Socket, Ejector Clip and Identification Label, 1Part Number for Simple Ordering AC & DC Coils, Supply Status LED as Standard 35mm Din Rail Mounting, 2 Socket Types For Ease of Installation, 12A and 16A Versions | |
| Relay Switching Classification | Interface Relay Module | |
| Dimensions | 75 x 15.8 x 52mm | |
| Control Resistance | 100mΩ | |
| Turn On Time | 15ms | |
| Minimum Operating Temperature | -40°C | |
| Turn Off Time | 8ms | |
| Life | 100000 (AC, Mechanical), 100000 (DC, Electrical), 10000000 (DC, Mechanical), 50000 (AC, Electrical) | |
Select all | ||
|---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 24V dc | ||
Contact Configuration DPDT | ||
Mounting Type DIN Rail | ||
Number of Poles 2 | ||
Series 2RM | ||
Load Current Rating 8A | ||
Maximum Input Voltage 250V ac | ||
Switching Voltage 24 V dc → 250V ac | ||
Terminal Type Screw | ||
Depth 15.8mm | ||
Height 52mm | ||
Length 75mm | ||
Contact Material Silver Alloy | ||
Input Current 8A | ||
Maximum Operating Temperature +85°C | ||
Standards Met CE, cURus | ||
Operating Temperature Range -40 → +85°C | ||
Special Features Change Over Contacts, Supplied Complete, Relay, LED, Socket, Ejector Clip and Identification Label, 1Part Number for Simple Ordering AC & DC Coils, Supply Status LED as Standard 35mm Din Rail Mounting, 2 Socket Types For Ease of Installation, 12A and 16A Versions | ||
Relay Switching Classification Interface Relay Module | ||
Dimensions 75 x 15.8 x 52mm | ||
Control Resistance 100mΩ | ||
Turn On Time 15ms | ||
Minimum Operating Temperature -40°C | ||
Turn Off Time 8ms | ||
Life 100000 (AC, Mechanical), 100000 (DC, Electrical), 10000000 (DC, Mechanical), 50000 (AC, Electrical) | ||
- COO (Country of Origin):
- CN
Hongfa 2RM Series Relays
Features and Benefits
